Angle clamp Welding clamp set Design: Design and use: - body and jaws made of high-quality - solid body and base plate made of high quality cast iron cast iron, galvanised - copper-plated spindle prevents adhesion of weld spatter - trapezoid threaded spindle made of - angle range continuously adjustable from 5° - 180° steel, copper-plated, hence no - clamping aid for differently strong components at arbitrarily adhesion of welding beads adjustable angles - spindle nut flexible mounted - push-through toggle handle for high clamping force - lateral long slots for clamping on welding and machine tables 587700 Cast, galvanised 587702 SM 10 Clamping rangemm 587700 max. clamping widthmm902 ×   90 Clamping rangemm 587702 Jaw widthmm Weightkg 120  2 × 120 100-SET  35 10.66 Clamping element for welding table Design: Design: - tempered profile - tempered profile - sliding arm for springy and elastic tensioning - sliding arm for springy and elastic tensioning - infinitely adjustable outreach - infinitely adjustable outreach - smooth trapezoidal thread spindle - smooth trapezoidal thread spindle - pressure plate replaceable without tools - pressure plate replaceable without tools - for position-accurate, individual clamping - for position-accurate, individual clamping - with lever handle for fast and vibration-proof clamping 587800 with 2-component handle 587802 with lever handle 58 Bolt X/outreachmm16/100587800 max. clamping heightmm Design200fixed outreachBolt X/outreachmm 587802 max. clamping heightmm Design16/100200fixed outreach 16/150  200 variable outreach 16/150  200 variable outreach 28/120  300 fixed outreach 28/120  300 fixed outreach 28/140  300 fixed outreach 28/140  300 fixed outreach 28/175  300 variable outreach 28/175  300 variable outreach Design: Design: - adapts especially to round, oval and angular workpieces - accessories for speed clamps with horizontal base - stepless angle adjustment from 60° inside to 60° outside - with bolts for direct use on a welding table Type 16VAD/28VAD: - without bolts for screwing on the extension TWX - with bolt - for fast alignment and fixing of the workpiece at the welding table Type VAD: - without bolt - for variable displacement at the welding table 587810 Vario table clamping attachment 587812 Quick release adapter Type 587810 xmm Clamping surface widthmm16VAD1645 Bolt Xmm 587812 Fitting for 28VAD  28 45 16  299350 45 | 299350 65 | 299650 25 VAD  — 45 28  299350 45 | 299350 65 | 299650 25 58/1138 www.precitool.de Shears / Clamping Tools
