Short step drill HSS 90°
Cat. no. Factory Type 90°
N/mm HB - point geometry to DIN 1412 form A HSS
2 standard N
- drill point thinning from 3.20 mm Straight
104410 coated 118° shank
< 850 <300 - blank (104410)
104412 - TiAlN coating (104412) P
vc = m/min.
104410 16-32 20-32 Use:
For CNC and NC machines.
10 104412 32-45 30-40
Countersink fine, for efficient manufacturing of through holes to DIN EN 20273 and screw-head counterbores 90°. Form A and B to DIN 74, part 1, for screws to DIN 963 and DIN 964.
104410 PRECITOOL, fine
104412 PRECITOOL, fine, TiAlN
104410
| for threads | 104410 104412 | d | d | l | l | l | d | f | |
| mm1 | mm3 | mm1 | mm2 | mm3 | mm2 | mm/U | |||
| M3 | | | 3�2 | 6�0 | 66 28 | 9 | 6�0 0�040 - 0�063 | ||
| M4 | | | 4�3 | 8�0 | 79 37 | 11 | 8�0 0�050 - 0�080 | ||
| M5 | | | 5�3 10�0 | 89 43 | 13 10�0 0�050 - 0�080 | ||||
| M6 | | | 6�4 11�5 | 95 47 | 15 11�5 0�063 - 0�100 | ||||
| M8 | | | 8�4 15�0 111 56 | 19 15�0 0�080 - 0�125 | |||||
| M10 | | | 10�5 19�0 127 64 | 23 19�0 0�100 - 0�160 |
104412
Short step drill HSS 90°
P K Design:
Cat. no. Factory Type 90° P
N/mm2 HB - point geometry to DIN 1412 form A HSS
- drill point thinning from 3.40 mm standard N Straight
104420 < 850 <300 118° shank
- blank vc = m/min.
104420 16-32 20-32 Use:
For CNC and NC machines. Countersink medium, for efficient manufacture of through holes to DIN EN 20273 and screw-head counterbores 90°. Form A and B to DIN 74, part 1, for screws to DIN 7991.
104420 PRECITOOL, medium
| for threads | 104420 | d | d | l | l | l | d | f | |
| mm1 | mm3 | mm1 | mm2 | mm3 | mm2 | mm/U | |||
| M3 | | 3�4 | 6�6 | 70 | 31 | 9 | 6�6 | 0�040 - 0�063 | |
| M4 | | 4�5 | 9�0 | 84 | 40 | 11 | 9�0 | 0�050 - 0�080 | |
| M5 | | 5�5 | 11�0 | 95 | 47 | 13 | 11�0 | 0�050 - 0�080 | |
| M6 | | 6�6 | 13�0 | 102 | 51 | 15 | 13�0 | 0�063 - 0�100 | |
| M8 | | 9�0 | 17�2 | 123 | 62 | 19 | 17�2 | 0�080 - 0�125 | |
| M10 | | 11�0 | 21�5 | 141 | 70 | 23 | 21�5 | 0�100 - 0�160 |
Short step drill HSS 90°
P K Design:
Cat. no. Factory Type 90°
N/mm HB - point geometry to DIN 1412 form A HSS
2 standard N Straight
- drill point thinning from 2.50 mm 118°
104430 coated shank
< 850 <300 - blank (104430)
104432 - TiAlN coating (104432) P
vc = m/min.
104430 16-32 20-32 Use:
For CNC and NC machines. For tapped
104432 32-45 30-40
holes to DIN 336, countersinking 90° to DIN 20273
104430 PRECITOOL, core drilling
104432 PRECITOOL, core drilling, TiAlN
104430
| d | d | l | l | l | d | f | |||
| for threads | 104430 104432 | 1 | 3 | 1 | 2 | 3 | 2 | ||
| mm | mm | mm | mm | mm | mm | mm/U | |||
| M3 | | | 2�5 | 3�4 | 52 20 | 8�8 | 3�4 0�040 - 0�063 | ||
| M4 | | | 3�3 | 4�5 | 58 24 11�4 | 4�5 0�050 - 0�080 | |||
| M5 | | | 4�2 | 5�5 | 66 28 13�6 | 5�5 0�050 - 0�080 | |||
| M6 | | | 5�0 | 6�6 | 70 31 16�5 | 6�6 0�063 - 0�100 | |||
| M8 | | | 6�8 | 9�0 | 84 40 21�0 | 9�0 0�080 - 0�125 | |||
| M10 | | | 8�5 11�0 | 95 47 25�5 11�0 0�080 - 0�125 | |||||
| M12 | | | 10�2 13�5 107 54 30�0 13�5 0�100 - 0�160 | 104432 |
