Carbide Micrograin Carbide End Mills List 402, 403, 404 (Continued) SPEEDFEED CARBIDEP1105-1108TiAINTiCN BR 30˚ 2, 3, or 4 Flute, Inch Sizes Milling Diameter Tolerance 1/32≤D≤1 +0 / -0.002" 402 404 403 EDP Number Mill Overall Length Shank List 402 (2 Flute) List 403 (3 Flute) List 404 (4 Flute) Diameter Length of Cut Diameter Bright TiCN TiAlN Bright TiAlN Bright TiAlN D L Lc d 402-5625 402-562508 402-562511 403-5625 403-562511 404-5625 404-562511 9/16 3-1/2 1-1/8 9/16 402-6250 — 402-625011 403-6250 403-625011 404-6250 404-625011 5/8 3-1/2 1-1/4 5/8 402-6875 — 402-687511 403-6875 403-687511 404-6875 404-687511 11/16 4 1-3/8 3/4 402-7500 — 402-750011 403-7500 403-750011 404-7500 404-750011 3/4 4 1-1/2 3/4 402-8750 — 402-875011 403-8750 403-875011 404-8750 404-875011 7/8 4 1-1/2 7/8 402-1000 — 402-100011 403-1000 403-100011 404-1000 404-100011 1 4 1-1/2 1 Packed: 1 pc. EDP’s listed above are stocked standard, other coatings available upon request. Specify treatment at time of order. Work Material P M K N S H Carbon Steels AlloyList No.Low10101018Med.10351045HighSteelsDie10654140Steels4340Stainless SteelsCast30040017-4 PHIronAluminumNickelAlloyTitaniumHardened Steels60617075CastingInconel6Al4V(30 HRC)~35HRC35-4545-5050-70HRCHRCHRC 402 403 404 good best 874 Carbide Square & Corner Radius WWW.OSGTOOL.COM
