HY-PRO® CARB Performance Sub-Micrograin Carbide End Mills List HP460 SPEEDFEED CARBIDEP1083-1084TiAIN SHANK60˚h6 3 Flute, Inch Sizes, High Helix Milling Diameter Tolerance 1/8≤D≤1 +0 / -0.0015" EDP Mill Overall Length Shank EDP Mill Overall Length Shank Number Diameter Length of Cut Diameter Number Diameter Length of Cut Diameter TiAlN D L Lc d TiAlN D L Lc d HP460-1250 1/8 1-1/2 1/2 1/8 HP460-4375 7/16 2-3/4 1 7/16 HP460-1875 3/16 2 5/8 3/16 HP460-5000 1/2 3 1 1/2 HP460-2500 1/4 2-1/2 3/4 1/4 HP460-6250 5/8 3-1/2 1-1/4 5/8 HP460-3125 5/16 2-1/2 13/16 5/16 HP460-7500 3/4 4 1-1/2 3/4 HP460-3750 3/8 2-1/2 1 3/8 HP460-1000 1 4 1-1/2 1 Packed: 1 pc. Available TiAlN coating only. List HP460 SPEEDFEED CARBIDEP1083-1084TiAIN SHANK60˚h6 3 Flute, Metric Sizes, High Helix Milling Diameter Tolerance 3≤D≤25 +0 / -0.038mm EDP Mill Overall Length Shank EDP Mill Overall Length Shank Number Diameter Length of Cut Diameter Number Diameter Length of Cut Diameter TiAlN D L Lc d TiAlN D L Lc d HP460-1181 3 64 12 6 HP460-4724 12 76 25 12 HP460-1575 4 64 14 6 HP460-5512 14 89 29 14 HP460-1968 5 64 16 6 HP460-6299 16 89 32 16 HP460-2362 6 64 19 6 HP460-7087 18 102 38 18 HP460-3150 8 64 21 8 HP460-7874 20 102 38 20 HP460-3937 10 70 25 10 HP460-9843 25 102 38 25 Packed: 1 pc. Available TiAlN coating only. OSG's Performance & Savings Want to turbo-charge performance? Try EXOCARB® WXL® - List 4445 (p. 765) Work Material P M K N S H Carbon Steels AlloyList No.Low10101018Med.10351045HighSteelsDie10654140Steels4340Stainless SteelsCast30040017-4 PHIronAluminumNickelAlloyTitaniumHardened Steels60617075CastingInconel6Al4V(30 HRC)~35HRC35-4545-5050-70HRCHRCHRC HP460 good best WWW.OSGTOOL.COM HY-PRO® CARB Square End 851
