DD d2d2 dd EXOCARB® AERO UVX-Ti Variable Lead End Mill for Titanium Alloy List 2104 SPEEDNEWFEEDCARBIDEP1059EXO® SHANKREGVar.˚h6 UVX-TI-LN-5FL, 5 Flute, Regular Length, Reduced Neck, Square End Milling Diameter Tolerance 12 ≤ D ≤ 25 +0/-0.05mm Lc L1 L Mill DiameterEDP Number OverallLength Length of Cut Neck Length Neck Diameter Shank Diameter D L Lc L1 d2 d 8555320 12 90 24 36 11.5 12 8555360 16 100 32 48 15.5 16 8555400 20 120 40 60 19.5 20 8555450 25 140 50 75 24.5 25 Packed: 1 pc. Available EXO® coating only. List 2102 SPEEDNEWFEEDCARBIDEP1058EXO® SHANKREGVar.˚h6 UVX-TI-LN-5FL, 5 Flute, Regular Length, Reduced Neck, Square End Milling Diameter Tolerance 1/2 ≤ D ≤ 1-1/4 +0 / -0.002" Lc L1 L Mill DiameterEDP Number OverallLength Length of Cut Neck Length Neck Diameter Shank Diameter D L Lc L1 d2 d 21020011 1/2 3-1/2 1 1-1/2 0.480 1/2 21020111 5/8 4 1-1/4 1-7/8 0.605 5/8 21020211 3/4 6-1/2 1-1/2 2-1/4 0.730 3/4 21020311 1 5-1/2 2 3 0.980 1 21020411 1-1/4 6 2-1/2 3-3/4 1.230 1 Packed: 1 pc. Available EXO® coating only. Work Material P M K N S H Carbon Steels AlloyList No.Low10101018Med.10351045HighSteelsDie10654140Steels4340Stainless SteelsCast30040017-4 PHIronAluminumNickelAlloyTitaniumHardened Steels60617075CastingInconel6Al4V(30 HRC)~35HRC35-4545-5050-70HRCHRCHRC 2104 2102 good best 808 EXOCARB® AERO WWW.OSGTOOL.COM
