HY-PRO® CARB
Performance Carbide Drills

List HP245 (Continued) SPEED
FEED
P312
CARBIDE
WD1 30˚
5D

Flute Overall Shank
Diameter
EDP Length Length Diameter
Number Fractional Wire Gage Letter Size mm Inch FL L d
Size
HP245-1890 - 12 - 4.80 0.1890
HP245-1929 - - - 4.90 0.1929
HP245-1969 - - - 5.00 0.1969
HP245-2008 - - - 5.10 0.2008
HP245-2031 13/64 - - 5.16 0.2031
HP245-2047 - - - 5.20 0.2047
HP245-2087 - - - 5.30 0.2087
HP245-2126 - - - 5.40 0.2126
HP245-2130 - 3 - 5.41 0.2130 44 82 6
HP245-2165 - - - 5.50 0.2165
HP245-2189 7/32 - - 5.56 0.2189
HP245-2205 - - - 5.60 0.2205
HP245-2244 - - - 5.70 0.2244
HP245-2283 - - - 5.80 0.2283
HP245-2323 - - - 5.90 0.2323
HP245-2343 15/64 - - 5.95 0.2343
HP245-2362 - - - 6.00 0.2362
HP245-2402 - - - 6.10 0.2402
HP245-2441 - - - 6.20 0.2441
HP245-2480 - - - 6.30 0.2480
HP245-2500 1/4 - E 6.35 0.2500
HP245-2520 - - - 6.40 0.2520
HP245-2559 - - - 6.50 0.2559
HP245-2571 - - F 6.53 0.2571
HP245-2598 - - - 6.60 0.2598
HP245-2638 - - - 6.70 0.2638
HP245-2657 17/64 - - 6.75 0.2657
HP245-2677 - - - 6.80 0.2677
HP245-2717 - - I 6.90 0.2717
HP245-2756 - - - 7.00 0.2756
53 91 8
HP245-2795 - - - 7.10 0.2795
HP245-2811 9/32 - - 7.14 0.2811
HP245-2835 - - - 7.20 0.2835
HP245-2874 - - - 7.30 0.2874
HP245-2913 - - - 7.40 0.2913
HP245-2953 - - - 7.50 0.2953
HP245-2969 19/64 - - 7.54 0.2969
HP245-2992 - - - 7.60 0.2992
HP245-3031 - - - 7.70 0.3031
HP245-3071 - - - 7.80 0.3071
HP245-3110 - - - 7.90 0.3110
HP245-3126 5/16 - - 7.94 0.3126
HP245-3150 - - - 8.00 0.3150
HP245-3189 - - - 8.10 0.3189
HP245-3228 - - P 8.20 0.3228 61 103 10
HP245-3268 - - - 8.30 0.3268
Packed: 1 pc.
Available WD1 coating only.

Work Material
P M K N S H
Carbon Steels Alloy Nickel
Steels Stainless Steels Aluminum Alloy Titanium Hardened Steels
List No. Low Med. High Die Cast
1010 1035 4140 Steels Iron 6061 Casting Inconel 6Al4V ~35 35-45 45-50 50-70
1018 1045 1065 4340 300 400 17-4 PH 7075 (30 HRC) HRC HRC HRC HRC
HP245
good best
