® PSF 90° Shoulder Cutter List 52901 SPEEDFEED P1217 PSF Bore (Inch) Recommended Materials: p1217 Accessories & Inserts: p1216 EDP No. Body TeethTypeTypeDesignation Tool Tool FlangeDia.No.HeightDia.Type(inch)of(inch)(inch)TeethBoreHoleDia.(inch)KeywayKeywayWidthDepthApplicable(inch)(inch)Insert D H D2 d3 a b 52901000 PSF09R200A075-6 1 2.000 6 1.575 1.772 0.750 0.315 0.197 52901001 Bore Normal PSF09R250A075-7 1 2.500 7 1.575 1.968 0.750 0.315 0.197 SD_T09… 52901002 PSF09R300A100-9 1 3.000 9 1.968 2.362 1.000 0.375 0.236 Packed: 1 pc. List 78130 SPEEDFEED P1217 PSF Bore (Metric) Recommended Materials: p1217 Accessories & Inserts: p1216 EDP No. Body TeethTypeTypeDesignation Type Tool Tool FlangeDia.No.HeightDia.(mm)of(mm)(mm)TeethBoreHoleDia.(mm)KeywayKeywayWidthDepthApplicable(mm)(mm)Insert D H D2 d3 a b 7803011 PSF09R050M22-6 1 50 6 40 45 22 10.4 6.3 7803012 Bore Normal PSF09R063M22-7 1 63 7 40 50 22 10.4 6.3 SD_T09… 7803013 PSF09R080M25.4-9 1 80 9 50 60 25.4 9.5 6 Packed: 1 pc. Note: This item is stocked overseas. Please contact OSG for availability and delivery. Type 1 ØD2 Ød3 a ØD With coolant hole. WWW.OSGTOOL.COM OSG PHOENIX® PSF 1215 b H
