TYPHOON - high performance solid carbide drills
3584HTA
8XD OSAWA INFO NORM
4-margin lands, long (8xD)
CARBIDE DRILLS
PU-HPU
| P M | K N | S H |
| H H | H I | I |
| H1st choiceI | suitable |
HRC H 1st choice I suitable SUH MINI HL HSD C-SD-TA
| D(m7) | D Tol. | d(h6) | l | l1 | L | EDP No. | Stock | |
| 3.00 | +0.012/+0.002 | 6 | 32 | 40 | 85 | 358HTA0300 | h | |
| 3.10 | +0.016/+0.004 | 6 | 32 | 40 | 85 | 358HTA0310 | h | |
| 3.20 | +0.016/+0.004 | 6 | 32 | 40 | 85 | 358HTA0320 | h | |
| 3.30 | +0.016/+0.004 | 6 | 32 | 40 | 85 | 358HTA0330 | h | |
| HSS | 3.40 | +0.016/+0.004 | 6 | 32 | 40 | 85 | 358HTA0340 | h |
| DRILLS | 3.50 | +0.016/+0.004 | 6 | 32 | 40 | 85 | 358HTA0350 | h |
| 3.60 | +0.016/+0.004 | 6 | 36 | 40 | 85 | 358HTA0360 | h | |
| LFTA SUTA | 3.70 | +0.016/+0.004 | 6 | 36 | 40 | 85 | 358HTA0370 | h |
| HSS-HSS/CO | 3.80 | +0.016/+0.004 | 6 | 36 | 40 | 85 | 358HTA0380 | h |
| 3.90 | +0.016/+0.004 | 6 | 36 | 40 | 85 | 358HTA0390 | f | |
| 4.00 | +0.016/+0.004 | 6 | 38 | 46 | 85 | 358HTA0400 | h | |
| 4.10 | +0.016/+0.004 | 6 | 38 | 46 | 85 | 358HTA0410 | h | |
| 4.20 | +0.016/+0.004 | 6 | 38 | 46 | 85 | 358HTA0420 | h | |
| 4.30 | +0.016/+0.004 | 6 | 40 | 46 | 97 | 358HTA0430 | h | |
| 4.40 | +0.016/+0.004 | 6 | 40 | 46 | 97 | 358HTA0440 | f | |
| CARBIDE | 4.50 | +0.016/+0.004 | 6 | 44 | 46 | 97 | 358HTA0450 | h |
| END-MILLS | 4.60 | +0.016/+0.004 | 6 | 44 | 46 | 97 | 358HTA0460 | h |
| 4.70 | +0.016/+0.004 | 6 | 44 | 46 | 97 | 358HTA0470 | h | |
| G2 MDTA | 4.80 | +0.016/+0.004 | 6 | 44 | 46 | 97 | 358HTA0480 | h |
| HF VH/UP | 4.90 | +0.016/+0.004 | 6 | 44 | 46 | 97 | 358HTA0490 | f |
| MEF | 5.00 | +0.016/+0.004 | 6 | 48 | 57 | 97 | 358HTA0500 | h |
| ALU | 5.10 | +0.016/+0.004 | 6 | 48 | 57 | 97 | 358HTA0510 | h |
| MEX/MH UH/MH | 5.20 | +0.016/+0.004 | 6 | 48 | 57 | 97 | 358HTA0520 | h |
| 5.30 | +0.016/+0.004 | 6 | 48 | 57 | 97 | 358HTA0530 | h | |
| 5.40 | +0.016/+0.004 | 6 | 48 | 57 | 97 | 358HTA0540 | f | |
| 5.50 | +0.016/+0.004 | 6 | 48 | 57 | 97 | 358HTA0550 | h | |
| 5.60 | +0.016/+0.004 | 6 | 48 | 57 | 97 | 358HTA0560 | h | |
| 5.70 | +0.016/+0.004 | 6 | 48 | 57 | 97 | 358HTA0570 | f | |
| 5.80 | +0.016/+0.004 | 6 | 48 | 57 | 97 | 358HTA0580 | h | |
| HSS | 5.90 | +0.016/+0.004 | 6 | 48 | 57 | 97 | 358HTA0590 | h |
| END-MILLS | 6.00 | +0.016/+0.004 | 6 | 48 | 57 | 97 | 358HTA0600 | h |
| 6.10 | +0.021/+0.006 | 8 | 64 | 76 | 116 | 358HTA0610 | h | |
| 6.20 | +0.021/+0.006 | 8 | 64 | 76 | 116 | 358HTA0620 | h | |
| 6.30 | +0.021/+0.006 | 8 | 64 | 76 | 116 | 358HTA0630 | h | |
| 6.40 | +0.021/+0.006 | 8 | 64 | 76 | 116 | 358HTA0640 | f | |
| 6.50 | +0.021/+0.006 | 8 | 64 | 76 | 116 | 358HTA0650 | h | |
| 6.60 | +0.021/+0.006 | 8 | 64 | 76 | 116 | 358HTA0660 | f | |
| 6.70 | +0.021/+0.006 | 8 | 64 | 76 | 116 | 358HTA0670 | h | |
| CARBIDE BURRS | 6.80 | +0.021/+0.006 | 8 | 64 | 76 | 116 | 358HTA0680 | h |
