Общий каталог Osawa 2021 - страница 212
Навигация
Общий каталог Osawa 2018
SUTA - High performance drills
990SUTA
self centering, stainless steel, short
OSAWA NORM INFO
CARBIDE DRILLS
PU-HPU
| P M K N | S H |
| H H H | I |
| H1st choiceIsuitable |
TA-4HTA SUH ALH HRC H 1st choice I suitable SUH MINI HL HSD C-SD-TA
| D(h8) | D Tol. | d(h7) | l | L | PACKAGING | EDP No. | Stock | |
| 15.60 | 0/-0.027 | 15.6 | 112 | 172 | 1 | P990SUTA1560 | h | |
| 16.00 | 0/-0.027 | 16 | 112 | 172 | 1 | P990SUTA1600 | h | |
| 16.50 | 0/-0.027 | 16.5 | 115 | 181 | 1 | P990SUTA1650 | h | |
| 17.00 | 0/-0.027 | 17 | 115 | 181 | 1 | P990SUTA1700 | h | |
| 17.50 | 0/-0.027 | 17.5 | 118 | 184 | 1 | P990SUTA1750 | h | HSS |
| 17.6 | 0/-0.027 | 17.6 | 118 | 184 | 1 | P990SUTA1760 | h | DRILLS |
| 18.00 | 0/-0.027 | 18 | 118 | 184 | 1 | P990SUTA1800 | h | |
| 18.50 | 0/-0.033 | 18.5 | 122 | 188 | 1 | P990SUTA1850 | h | LFTA |
| 19.00 | 0/-0.033 | 19 | 122 | 188 | 1 | P990SUTA1900 | h | SUTA HSS-HSS/CO |
| 19.50 | 0/-0.033 | 19.5 | 125 | 191 | 1 | P990SUTA1950 | h | |
| 20.00 | 0/-0.033 | 20 | 125 | 191 | 1 | P990SUTA2000 | h |
CARBIDE END-MILLS
G2 MDTA HF VH/UP MEF ALU MEX/MH UH/MH
HSS END-MILLS
CARBIDE BURRS
h stock standard f non-standard stock m stock exhaustion
