SUTA - High performance drills

990SUTA

OSAWA INFO NORM

self centering, stainless steel, short

CARBIDE DRILLS

PU-HPU TA-4HTA SUH ALH HRC SUH MINI HL HSD C-SD-TA

P	M	K	N	S	H
H	H		H	I

H 1st choice I suitable

D(h8)	D Tol.	d(h7)	l	L	PACKAGING	EDP No.	Stock
9.80	0/-0.022	9.8	87	137	1	P990SUTA0980	h
9.90	0/-0.022	9.9	87	137	1	P990SUTA0990	h
10.00	0/-0.022	10	87	137	1	P990SUTA1000	h
10.10	0/-0.027	10.1	87	144	1	P990SUTA1010	h
10.20	0/-0.027	10.2	87	144	1	P990SUTA1020	h
10.30	0/-0.027	10.3	87	144	1	P990SUTA1030	h
10.40	0/-0.027	10.4	87	144	1	P990SUTA1040	h
10.50	0/-0.027	10.5	87	144	1	P990SUTA1050	h
10.60	0/-0.027	10.6	87	144	1	P990SUTA1060	h
10.70	0/-0.027	10.7	94	151	1	P990SUTA1070	h
10.80	0/-0.027	10.8	94	151	1	P990SUTA1080	h
10.90	0/-0.027	10.9	94	151	1	P990SUTA1090	h
11.00	0/-0.027	11	94	151	1	P990SUTA1100	h
11.10	0/-0.027	11.1	94	151	1	P990SUTA1110	h
11.20	0/-0.027	11.2	94	151	1	P990SUTA1120	h
11.30	0/-0.027	11.3	94	151	1	P990SUTA1130	h
11.40	0/-0.027	11.4	94	151	1	P990SUTA1140	h
11.50	0/-0.027	11.5	94	151	1	P990SUTA1150	h
11.60	0/-0.027	11.6	94	151	1	P990SUTA1160	h
11.70	0/-0.027	11.7	94	151	1	P990SUTA1170	h
11.80	0/-0.027	11.8	94	151	1	P990SUTA1180	h
11.90	0/-0.027	11.9	101	158	1	P990SUTA1190	h
12.00	0/-0.027	12	101	158	1	P990SUTA1200	h
12.10	0/-0.027	12.1	101	158	1	P990SUTA1210	h
12.20	0/-0.027	12.2	101	158	1	P990SUTA1220	h
12.30	0/-0.027	12.3	101	158	1	P990SUTA1230	h
12.40	0/-0.027	12.4	101	158	1	P990SUTA1240	h
12.50	0/-0.027	12.5	101	158	1	P990SUTA1250	h
12.60	0/-0.027	12.6	101	158	1	P990SUTA1260	h
12.70	0/-0.027	12.7	101	158	1	P990SUTA1270	h
12.80	0/-0.027	12.8	101	158	1	P990SUTA1280	h
12.90	0/-0.027	12.9	101	158	1	P990SUTA1290	h
13.00	0/-0.027	13	101	158	1	P990SUTA1300	h
13.50	0/-0.027	13.5	106	166	1	P990SUTA1350	h
14.00	0/-0.027	14	106	166	1	P990SUTA1400	h
14.10	0/-0.027	14.1	109	169	1	P990SUTA1410	h
14.50	0/-0.027	14.5	109	169	1	P990SUTA1450	h
15.00	0/-0.027	15	109	169	1	P990SUTA1500	h
15.50	0/-0.027	15.5	112	172	1	P990SUTA1550	h

Общий каталог Osawa 2021 - страница 211
