LFTA - High performance drills

238LFTA

DIN INFO 338

self-centering, general purpose, short

CARBIDE DRILLS

PU-HPU TA-4HTA SUH ALH HRC SUH MINI HL HSD C-SD-TA

P	M	K	N	S	H
H	I	H	I

H 1st choice I suitable

D(h8) 9.80	D Tol. 0/-0.022	d(h7) 9.8	l 87	L 133	PACKAGING 1	EDP No. P238LFTA0980	Stock h
9.90	0/-0.022	9.9	87	133	1	P238LFTA0990	h
10.00	0/-0.022	10	87	133	1	P238LFTA1000	h
10.20	0/-0.027	10.2	87	133	1	P238LFTA1020	h
10.30	0/-0.027	10.3	87	133	1	P238LFTA1030	h
10.50	0/-0.027	10.5	87	133	1	P238LFTA1050	h
10.80	0/-0.027	10.8	94	142	1	P238LFTA1080	h
11.00	0/-0.027	11	94	142	1	P238LFTA1100	h
11.20	0/-0.027	11.2	94	142	1	P238LFTA1120	h
11.30	0/-0.027	11.3	94	142	1	P238LFTA1130	h
11.50	0/-0.027	11.5	94	142	1	P238LFTA1150	h
11.80	0/-0.027	11.8	94	142	1	P238LFTA1180	h
12.00	0/-0.027	12	101	151	1	P238LFTA1200	h
12.20	0/-0.027	12.2	101	151	1	P238LFTA1220	h
12.50	0/-0.027	12.5	101	151	1	P238LFTA1250	h
12.80	0/-0.027	12.8	101	151	1	P238LFTA1280	h
13.00	0/-0.027	13	101	151	1	P238LFTA1300	h
13.30	0/-0.027	13.3	108	160	1	P238LFTA1330	h
13.50	0/-0.027	13.5	108	160	1	P238LFTA1350	h
13.80	0/-0.027	13.8	108	160	1	P238LFTA1380	h
14.00	0/-0.027	14	108	160	1	P238LFTA1400	h
14.50	0/-0.027	14.5	114	169	1	P238LFTA1450	h
14.80	0/-0.027	14.8	114	169	1	P238LFTA1480	h
15.00	0/-0.027	15	114	169	1	P238LFTA1500	h
15.30	0/-0.027	15.3	120	178	1	P238LFTA1530	h
15.50	0/-0.027	15.5	120	178	1	P238LFTA1550	h
15.80	0/-0.027	15.8	120	178	1	P238LFTA1580	h
16.00	0/-0.027	16	120	178	1	P238LFTA1600	h
16.50	0/-0.027	16.5	125	184	1	P238LFTA1650	h
17.00	0/-0.027	17	125	184	1	P238LFTA1700	h
17.50	0/-0.027	17.5	130	191	1	P238LFTA1750	h
18.00	0/-0.027	18	130	191	1	P238LFTA1800	h
18.50	0/-0.033	18.5	135	198	1	P238LFTA1850	h
19.00	0/-0.033	19	135	198	1	P238LFTA1900	h
19.50	0/-0.033	19.5	140	205	1	P238LFTA1950	h
20.00	0/-0.033	20	140	205	1	P238LFTA2000	h

Общий каталог Osawa 2021 - страница 201
