NC starting drills

C-SD-TA

INFO

solid carbide NC starting drills, 90°-120°

OSAWA NORM 90-120°

90°

CARBIDE DRILLS

PU-HPU TA-4HTA SUH ALH HRC SUH MINI HL HSD C-SD-TA

120°

P	M	K	N	S	H
H	H	H	H	I

H 1st choice I suitable

						C-SD-TA	90°	C-SD-TA	120°
D(h6)	D Tol.	d(h6)	l	l1	L	EDP No.	Stock	EDP No.	Stock
6.00	0/-0.008	6	16		50	CSDTA060A	h	CSDTA060B	h
8.00	0/-0.009	8	20		64	CSDTA080A	h	CSDTA080B	h
10.00	0/-0.009	10	25		70	CSDTA100A	h	CSDTA100B	h
12.00	0/-0.011	12	25		75	CSDTA120A	h	CSDTA120B	h
16.00	0/-0.011	16	26		90	CSDTA160A	h	CSDTA160B	h

LFTA SUTA HSS-HSS/CO

CARBIDE END-MILLS

G2 MDTA HF VH/UP MEF ALU MEX/MH UH/MH

HSS END-MILLS

CARBIDE BURRS

h stock standard f non-standard stock m stock exhaustion
