SG
OSAWA NORM INFO
TYPHOON TA-HTA-4HTA
TYPHOON PU-HPU
TYPHOON SUH
TYPHOON ALH
| Always Per l’uso Tragen Toujour Para usa При ра | wear gogg delle lim Sie immer s porter le r las limas боте с бор | les when u e rotative è die Schutz s lunettes rotativas e фрезами | sing the ro obbligato brille wenn de securité s obligator всегда исп | tary burrs rio indoss Sie die Fr en utilisan io usar ga ользуйте | are occhiali p äser benutz t les limes ro fas de prote защитные о | rotettivi en tatives cción чки | M | MPC | MN | F | ||
| D | d (3) | d (6) | l | L | ANGLE | PACKAGING | EDP No. | Stock | EDP No. | Stock | EDP No. | Stock |
| 3.0 | 3 | 6 | 38 | 5 | SG41M | h | SG41MPC | h | ||||
| 3.0 | 3 | 10 | 38 | 5 | SG43M | h | SG43MPC | h | ||||
| 3.0 | 3 | 14 | 38 | 5 | SG44M | h | SG44MPC | h | ||||
| 5.0 | 3 | 12.7 | 38 | 5 | SG53M | h | SG53MPC | h | ||||
| 6.0 | 6 | 18 | 50 | 5 | SG1M | h | SG1MPC | f | ||||
| 6.3 | 3 | 12.7 | 45 | 5 | SG51M | h | SG51MPC | h | ||||
| 8.0 | 6 | 19 | 64 | 5 | SG2M | h | SG2MPC | f | ||||
| 9.5 | 6 | 19 | 64 | 5 | SG3M | h | SG3MPC | f | ||||
| 12.7 | 6 | 19 | 64 | 5 | SG13M | f | SG13MPC | f | ||||
| 12.7 | 6 | 25 | 70 | 5 | SG5M | h | SG5MPC | f | ||||
| 16.0 | 6 | 25 | 70 | 5 | SG6M | h | SG6MPC | f | ||||
| 19.0 | 6 | 25 | 70 | 5 | SG7M | h | SG7MPC | f | ||||
| 19.0 | 6 | 38 | 83 | 5 | SG15M | f | SG15MPC | f |
TYPHOON
C-SD-TA
LFTA
SUTA
G2
MDTA
HF VH/UP
MEF
ALU
MEX
UH
HSS/CO-HSSP END MILLS
CARBIDE BURRS
