UH - < 70HRC - Corner radius INFO UHF4LN OSAWA <70 NORM cylindrical shank, 4F Unequal Pitch, TA-THYTPAH-4OHOTNA extended and reduced neck, corner radius CR CR TYPPHUO-HOPNU TYPHOSOUNH TYPHOAOLNH P M K N S H , , + actual length TYPHOHORNC + 1st choice , suitable TSYUPHHOMOINNI SQUARE RIB α actual length according to _ angle D D Tol. CR CR Tol. d(h6) l l1 d1 L z 30’ 1° 1°30’ 2° 3° EDP No. Stock TYPHOOHNL 3 0/-0.025 0.20 +/-0.010 6 3 25 2.80 75 4 26.21 27.11 28.07 29.07 - UHF4LN0300225 h 3 0/-0.025 0.30 +/-0.010 6 3 8 2.80 50 4 8.64 8.93 9.23 9.55 10.24 UHF4LN0300308 h 3 0/-0.025 0.30 +/-0.010 6 3 10 2.80 50 4 10.71 11.07 11.45 11.85 12.71 UHF4LN0300310 h C-SD-TA 3 0/-0.025 0.30 +/-0.010 6 3 12 2.80 50 4 12.77 13.20 13.66 14.14 15.18 UHF4LN0300312 h 3 0/-0.025 0.30 +/-0.010 6 3 14 2.80 50 4 14.84 15.34 15.87 16.44 17.64 UHF4LN0300314 h 3 0/-0.025 0.30 +/-0.010 6 3 16 2.80 60 4 16.91 17.48 18.09 18.73 20.11 UHF4LN0300316 h LFTA 3 0/-0.025 0.30 +/-0.010 6 3 18 2.80 60 4 18.98 19.62 20.30 21.02 22.58 UHF4LN0300318 h 3 0/-0.025 0.30 +/-0.010 6 3 20 2.80 60 4 21.04 21.76 22.52 23.32 25.05 UHF4LN0300320 h 3 0/-0.025 0.30 +/-0.010 6 3 30 2.80 75 4 31.38 32.45 33.59 34.79 - UHF4LN0300330 h SUTA 3 0/-0.025 0.50 +/-0.010 6 3 8 2.80 50 4 8.63 8.91 9.21 9.52 10.20 UHF4LN0300508 h 3 0/-0.025 0.50 +/-0.010 6 3 10 2.80 50 4 10.7 11.05 11.42 11.82 12.66 UHF4LN0300510 h HSS-HDSSR/ILCLOS 3 0/-0.025 0.50 +/-0.010 6 3 12 2.80 50 4 12.77 13.19 13.64 14.11 15.13 UHF4LN0300512 h 3 0/-0.025 0.50 +/-0.010 6 3 14 2.80 50 4 14.83 15.33 15.85 16.41 17.60 UHF4LN0300514 h 3 0/-0.025 0.50 +/-0.010 6 3 16 2.80 60 4 16.9 17.47 18.07 18.70 20.07 UHF4LN0300516 h G2 3 0/-0.025 0.50 +/-0.010 6 3 18 2.80 60 4 18.97 19.61 20.28 20.99 22.53 UHF4LN0300518 h 3 0/-0.025 0.50 +/-0.010 6 3 20 2.80 60 4 21.04 21.75 22.50 23.29 25.00 UHF4LN0300520 h 3 0/-0.025 0.50 +/-0.010 6 3 30 2.80 75 4 31.37 32.44 33.57 34.76 - UHF4LN0300530 h MDTA 4 0/-0.025 0.30 +/-0.010 6 4 10 3.70 60 4 10.90 11.26 11.65 12.06 12.93 UHF4LN0400310 h 4 0/-0.025 0.30 +/-0.010 6 4 15 3.70 60 4 16.07 16.61 17.19 17.79 19.10 UHF4LN0400315 h 4 0/-0.025 0.30 +/-0.010 6 4 20 3.70 60 4 21.24 21.96 22.72 23.53 - UHF4LN0400320 h HF VH/UP 4 0/-0.025 0.30 +/-0.010 6 4 25 3.70 75 4 26.4 27.31 28.26 - - UHF4LN0400325 h 4 0/-0.025 0.30 +/-0.010 6 4 32 3.70 75 4 33.64 34.79 36.01 - - UHF4LN0400332 h 4 0/-0.025 0.30 +/-0.010 6 4 40 3.70 75 4 41.91 43.35 - - - UHF4LN0400340 h MEF 4 0/-0.025 0.50 +/-0.010 6 4 10 3.70 60 4 10.89 11.25 11.63 12.03 12.89 UHF4LN0400510 h 4 0/-0.025 0.50 +/-0.010 6 4 15 3.70 60 4 16.06 16.60 17.17 17.76 19.06 UHF4LN0400515 h 4 0/-0.025 0.50 +/-0.010 6 4 20 3.70 60 4 21.23 21.94 22.7 23.50 - UHF4LN0400520 h ALU 4 0/-0.025 0.50 +/-0.010 6 4 25 3.70 75 4 26.4 27.29 28.24 - - UHF4LN0400525 h 4 0/-0.025 0.50 +/-0.010 6 4 32 3.70 75 4 33.63 34.78 35.99 - - UHF4LN0400532 h 4 0/-0.025 0.50 +/-0.010 6 4 40 3.70 75 4 41.9 43.33 - - - UHF4LN0400540 h MEX UH HSSE/NCDO-MHISLSLPS CARBIDE BURRS h stock standard f non-standard stock m stock exhaustion 608
