HF HARD - Unequal pitch - 45° chamfer CUTTING PARAMETERS HF850 INFO Material Group P5 P6 M5 TTYAP-HHTOAO-4NHTA ISO 513 P4 M4 K4 P4 P5 M4 M5 K4 S1 H1 H4 H5 K4 S2 S3 Hardness/Rm 800-1000 N/mm² 900-1200 N/mm² 35-45 HRC ≤ 55 HRC TPYUP-HHPOUON _° x ae 5° x D 4° x D 3° x D 2° x D Vc (m/min) 80-100 60-80 40-60 30-50 D n fz Vf n fz Vf n fz Vf n fz Vf TSUYPHHOON (mm) (rpm) (mm/z) (mm/min) (rpm) (mm/z) (mm/min) (rpm) (mm/z) (mm/min) (rpm) (mm/z) (mm/min) RAMPING 6 4780 0.020 385 3720 0.019 280 2650 0.018 187 2120 0.027 232 8 3580 0.026 370 2790 0.024 270 1990 0.023 182 1590 0.035 226 TAYLPHHOON 10 2870 0.031 360 2230 0.029 260 1590 0.027 175 1270 0.043 216 12 2390 0.036 340 1860 0.033 245 1330 0.031 167 1060 0.049 206 14 2050 0.040 330 1590 0.037 240 1140 0.035 161 910 0.055 199 16 1790 0.045 320 1390 0.042 230 1000 0.039 157 800 0.061 195 THYRPCHOON 20 1430 0.054 310 1110 0.051 225 800 0.048 153 640 0.074 189 Material Group P5 P6 M5 TSUYPHHMOIONIN ISO 513 P4 M4 K4 P4 P5 M4 M5 K4 S1 H1 H4 H5 K4 S2 S3 Hardness/Rm 800-1000 N/mm² 900-1200 N/mm² 35-45 HRC ≤ 55 HRC THYLPHOON ap x ae D x 0.4D D x 0.4D D x 0.25D D x 0.25D Vc (m/min) 80-100 60-80 40-60 30-50 D n fz Vf n fz Vf n fz Vf n fz Vf C-SD-TA (mm) (rpm) (mm/z) (mm/min) (rpm) (mm/z) (mm/min) (rpm) (mm/z) (mm/min) (rpm) (mm/z) (mm/min) VERTICAL 6 4780 0.023 440 3720 0.021 310 2650 0.017 180 2120 0.016 140 8 3580 0.030 430 2790 0.027 300 1990 0.022 180 1590 0.021 130 LFTA 10 2870 0.036 410 2230 0.032 290 1590 0.027 170 1270 0.025 130 12 2390 0.041 390 1860 0.037 270 1330 0.031 160 1060 0.029 120 14 2050 0.046 380 1590 0.041 260 1140 0.034 160 910 0.032 120 16 1790 0.051 370 1390 0.046 260 1000 0.038 150 800 0.036 110 SUTA 20 1430 0.062 350 1110 0.056 250 800 0.047 150 640 0.043 110 HDSRSIL-LHSSS/CO G2 MDTA HF VH/UP MEF ALU MEX UH HENSSD/CMOIL-LHSSSP CBUARRRBSIDE PARAMETERS SUGGESTED WITH HIGH POWER MILLING CHUCK AND STABLE MACHINING CONDITION 465
