MILLING MILLING CUTTERS APKT CUTTERS APKT END MILL - APKT 100332/40 Ap DESIGNATION D d L L1 Ap Z α CATALOG # LT 745 W-W-D016/2* 16 16 100 25 9 2 10 M2001587 d D LT 745 WL-W-D016/2* 16 16 150 35 9 2 10 M2001849 LT 745 W-W-D020/3* 20 20 100 30 9 3 7 M2001589 LT 745 WL-W-D020/3* 20 20 150 35 9 3 7 M2001850 L1 LT 745 W-W-D025/3* 25 25 120 30 9 3 5 M2001591 L LT 745 WL-W-D025/4* 25 25 200 40 9 4 5 M2001851 LT 745 WL-W-D032/4* 32 32 200 40 9 4 3 M2001852 END MILL - APKT 060204 PDTR** LT 745 W-W-D032/5* 32 32 120 30 9 5 3 M2001848 *On RequestDESIGNATIONDdLL1ApZαoCATALOG # SCREW M2002181KEYM2000601 LT 752 C-W-D010/2 10 10 72 16 5.2 2 3.00 M2003098 LT 752 C-W-D012/3 12 12 80 26 5.2 3 2.20 M2003099 END MILL - APKT 160408 PDTR LT 752 CL-W-D012/3* 12 10 120 13.5 5.2 3 2.20 M2003078 LT 752 C-W-D016/4 16 16 90 32 5.2 4 1.50 M2003100 DESIGNATION D d L L1 Ap Z α CATALOG # LT 752 CL-W-D016/3* 16 14 160 13.5 5.2 3 1.50 M2003105 LT 731 W-W-D025/2 25 25 100 44 15 2 5 M2002966 LT 752 C-W-D020/5 20 20 100 40 5.2 5 1.15 M2003101 LT 731 WL-W-D025/2 25 25 220 90 15 2 5 M2002965 LT 752 CL-W-D020/4* 20 18 200 13.5 5.2 4 1.15 M2003080 LT 731 W-W-D032/3 32 32 110 50 15 3 3 M2002968 LT 752 C-W-D025/7 25 20 120 40 5.2 4 0.90 M2003102 LT 731 WL-W-D032/3 32 32 220 90 15 3 3 M2002967 LT 752 CL-W-D025/6* 25 20 220 15 5.2 4 0.90 M2003081 LT 731 W-W-D040/4 40 32 115 50 15 4 2.5 M2002970 *Available Q3 2017 SCREW M2001640 LT 731 WL-W-D040/4 40 32 220 90 15 4 2.5 M2002969 SCREW DRIVER HANDLE M2002922 SCREW M2000597 PRESET ADAPTER 0.4NM M2002923 KEY M2000602 TORX PLUS BIT M2003064 END MILL - APKT 1705 END MILL - APKT 100308 PDTR / APKT 100304 PDTR / APKT 100312 PDTR / APKT 100316 PDTR DESIGNATION D d L L1 Ap Z α CATALOG # DESIGNATION D d L L1 Ap Z α CATALOG # LT 737 W-W-D025/2 25 20 100 32 16 2 5 M2001833 LT 741 C-W-D016/2 16 16 100 25 9 2 7.50 M2002806 LT 737 WL-W-D025/2 25 25 210 40 16 2 5 M2001836 LT 741 CL-W-D016/2 16 16 150 35 9 2 7.50 M2002817 LT 737 W-W-D032/3 32 32 110 40 16 3 3 M2001834 LT 741 C-W-D018/2 18 20 100 30 9 2 6.00 M2002807 LT 737 WL-W-D032/3 32 32 200 65 16 3 3 M2001837 LT 741 C-W-D020/3 20 20 100 30 9 3 5.00 M2002808 LT 737 W-W-D040/4 40 32 115 45 16 4 2.5 M2001835 LT 741 CL-W-D020/3 20 20 150 35 9 3 5.00 M2002818 LT 737 WL-W-D040/4 40 32 200 45 16 4 2.5 M2001982 LT 741 C-W-D022/3 22 20 100 30 9 3 4.00 M2002809 SCREW M2000597 LT 741 C-W-D025/3 25 25 120 30 9 3 3.30 M2002810 KEY M2000602 LT 741 C-W-D025/4 25 25 120 30 9 4 3.30 M2002811 LT 741 CL-W-D025/4 25 25 200 40 9 4 3.30 M2002819 LT 741 C-W-D028/4 28 25 120 30 9 4 2.70 M2002812 LT 741 C-W-D030/4 30 25 120 30 9 4 2.30 M2002813 LT 741 W-W-D032/5 32 32 120 30 9 5 2.00 M2002814 LT 741 WL-W-D032/4 32 32 200 40 9 4 2.00 M2002820 SCREW M2002181 KEY M2000601 ** Due to the small size of these inserts, using a pre-set torque screw driver (0.4Nm) at all times is recommended. It is also recommended that during mounting, the insert should be held in place with a finger. 134 135
