Общий каталог Lamina Technologies 2019 - 2020 - страница 163

Предыдущая страница Следующая страница

Навигация

MACHINING CONDITIONS | MILLING - LT 3130 MACHINING CONDITIONS | MILLING - LT 3130 SEKT 12T3 AGSN LT 3130 SNKX 1205-45 LT 3130 DOC Feed Vc Suggested Starting DOC Feed Vc Suggested Starting Material Lamina Material [mm] [mm/z] [m/min] Parameters Material Lamina Material [mm] [mm/z] [m/min] Parameters Hardness Hardness Group Gr. N° Examples Group Gr. N° Examples min max min max min max DOC Feed Vc min max min max min max DOC Feed Vc C35, Ck45, 125 HB 190 350 265 C35, Ck45, 125 HB 350 265 Non Alloyed 1 1020, 1045, 190 HB 0.50 6.00 0.18 0.46 190 320 3.00 0.34 240 Non Alloyed 1 1020, 1045, 190 HB 0.50 5.00 0.16 0.34 190 320 3.00 0.30 240 1060, 28Mn6 250 HB 190 280 215 1060, 28Mn6 250 HB 280 215 180 HB 150 270 215 180 HB 270 215 42CrMo4, 0.36 0.30 42CrMo4, 0.28 150 0.26 St50, Ck60, 230 HB 150 230 200 St50, Ck60, 230 HB 230 200 Low Alloyed 2 0.50 6.00 0.15 3.00 Low Alloyed 2 0.50 5.00 0.14 3.00 P 4140, 4340, 280 HB 130 210 165 P 4140, 4340, 280 HB 210 165 100Cr6 0.32 0.27 100Cr6 0.26 130 0.24 350 HB 130 190 155 350 HB 190 155 220 HB 90 170 140 220 HB 170 140 X40CrMoV5, 0.32 0.27 X40CrMoV5, 0.28 90 0.26 280 HB 90 150 130 280 HB 150 130 High Alloyed 3 H13, M42, D3, 0.50 5.00 0.12 2.30 High Alloyed 3 H13, M42, D3, 0.50 5.00 0.11 3.00 S6-5-2, 12Ni19 320 HB 60 120 110 S6-5-2, 12Ni19 320 HB 120 110 0.26 0.24 0.24 60 0.22 350 HB 60 100 90 350 HB 100 90 304, 316, 180 HB 0.15 0.32 190 260 230 304, 316, 180 HB 0.14 190 260 230 Austenitic 4 0.50 6.00 3.00 0.27 Austenitic 4 0.50 5.00 0.30 3.00 0.26 X5CrNi18-9 240 HB 0.12 0.29 160 220 200 X5CrNi18-9 240 HB 0.11 160 220 200 X2CrNiN23-4, 290 HB 70 140 2.30 110 X2CrNiN23-4, 290 HB 140 110 M Duplex 5 0.50 5.00 0.12 0.26 0.24 M Duplex 5 0.50 4.00 0.11 0.25 70 2.50 0.22 S31500 310 HB 70 130 2.30 100 S31500 310 HB 130 100 Ferritic & 410, X6Cr17, 200 HB 6.00 0.32 150 220 3.00 0.27 200 Ferritic & 410, X6Cr17, 200 HB 5.00 0.30 150 220 0.26 200 6 0.50 0.15 6 0.50 0.14 3.00 Martensitic 17-4PH, 430 42 HRc 5.00 0.26 90 160 2.30 0.24 140 Martensitic 17-4PH, 430 42 HRc 4.00 0.25 90 160 0.22 140 SEKT 1204 AFTN LT 3130 SNKX 1607-45 LT 3130 DOC Feed Vc Suggested Starting DOC Feed Vc Suggested Starting Material Lamina Material [mm] [mm/z] [m/min] Parameters Material Lamina Material [mm] [mm/z] [m/min] Parameters Hardness Hardness Group Gr. N° Examples Group Gr. N° Examples min max min max min max DOC Feed Vc min max min max min max DOC Feed Vc C35, Ck45, 125 HB 350 265 C35, Ck45, 125 HB 350 265 Non Alloyed 1 1020, 1045, 190 HB 0.30 2.00 0.30 2.70 190 320 1.20 1.70 240 Non Alloyed 1 1020, 1045, 190 HB 0.50 6.50 0.16 0.58 190 320 4.00 0.46 240 1060, 28Mn6 250 HB 280 215 1060, 28Mn6 250 HB 280 215 180 HB 270 215 180 HB 270 215 42CrMo4, 150 1.50 42CrMo4, 0.50 150 0.40 St50, Ck60, 230 HB 2.50 230 200 St50, Ck60, 230 HB 230 200 Low Alloyed 2 0.30 1.60 0.30 0.90 Low Alloyed 2 0.50 6.50 0.14 4.00 P 4140, 4340, 280 HB 210 165 P 4140, 4340, 280 HB 210 165 100Cr6 130 1.40 100Cr6 0.44 130 0.36 350 HB 2.25 190 155 350 HB 190 155 220 HB 1.60 2.25 170 140 220 HB 170 140 X40CrMoV5, 90 1.20 X40CrMoV5, 0.44 90 0.36 280 HB 1.30 2.00 150 130 280 HB 150 130 High Alloyed 3 H13, M42, D3, 0.30 0.30 0.70 High Alloyed 3 H13, M42, D3, 0.50 6.50 0.11 3.00 S6-5-2, 12Ni19 320 HB 1.80 120 110 S6-5-2, 12Ni19 320 HB 120 110 1.10 60 1.00 0.36 60 0.32 350 HB 1.60 100 90 350 HB 100 90 304, 316, 180 HB 190 260 230 304, 316, 180 HB 0.14 0.44 190 260 230 Austenitic 4 0.30 1.50 0.30 1.00 0.90 0.80 Austenitic 4 0.50 6.50 4.00 0.34 X5CrNi18-9 240 HB 160 220 200 X5CrNi18-9 240 HB 0.11 0.40 160 220 200 X2CrNiN23-4, 290 HB 140 110 X2CrNiN23-4, 290 HB 140 110 M Duplex 5 0.30 1.20 0.30 0.65 70 0.80 0.50 M Duplex 5 0.50 5.00 0.11 0.36 70 3.00 0.30 S31500 310 HB 130 100 S31500 310 HB 130 100 Ferritic & 410, X6Cr17, 200 HB 1.50 0.70 150 220 0.90 0.60 200 Ferritic & 410, X6Cr17, 200 HB 6.50 0.44 150 220 4.00 0.34 200 6 0.30 0.30 6 0.50 0.14 Martensitic 17-4PH, 430 42 HRc 1.10 0.65 90 160 0.80 0.50 140 Martensitic 17-4PH, 430 42 HRc 5.00 0.40 90 160 3.00 0.30 140 322 323
