MagicDrill DRX  DRX (Drilling Depth:3×D) L1 L2 L3 3xD φDc φd φd1 φDc S20-DRX...-03 3D  Toolholder Dimensions No. of Inserts Dimension (mm) Spare Parts Max. Clamp Screw Wrench Description Std. Offset Applicable Inserts φDc L1 L2 L3 φd φd1 (Radial) K38 (mm) S20 -DRX120M-3-03 ● 12 100 57 36 +0.5 Outer edge ZXMT030203UU-E -DRX125M-3-03 ● 2 12.5 102 59 37.5 20 27 +0.4 SB-2042TRG DTM-6 Inner edge ZXMT030203GM-I -DRX130M-3-03 ● 13 103 60 39 +0.3 -DRX135M-3-04 ● 13.5 105 62 40.5 +0.5 -DRX140M-3-04 ● 2 14 106 63 42 20 27 +0.4 SB-2042TRG DTM-6 ZXMT040203 U U -DRX145M-3-04 ● 14.5 108 65 43.5 +0.3 -DRX150M-3-04 ● 15 109 66 45 +0.2 S25 -DRX155M-3-05 ● 15.5 124 70 46.5 +0.8 -DRX160M-3-05 ● 16 126 72 48 +0.7 K -DRX165M-3-05 ● 2 16.5 127 73 49.5 25 32 +0.5 SB-2045TR DTM-6 ZXMT05T203 U U -DRX170M-3-05 ● 17 129 75 51 +0.4 -DRX175M-3-05 ● 17.5 130 76 52.5 +0.3 -DRX180M-3-05 ● 18 132 78 54 +0.2 -DRX185M-3-06 ● 18.5 131 77 55.5 +0.9 -DRX190M-3-06 ● 19 132 78 57 +0.8 Drilling -DRX195M-3-06 ● 19.5 134 80 58.5 +0.7 -DRX200M-3-06 ● 2 20 135 81 60 25 32 +0.5 SB-2250TR DTM-7 ZXMT06T204 U U -DRX205M-3-06 ● 20.5 137 83 61.5 +0.4 -DRX210M-3-06 ● 21 138 84 63 +0.3 -DRX215M-3-06 ● 21.5 140 86 64.5 +0.2 DRA -DRX220M-3-07 ● 22 141 87 66 +1.2 -DRX225M-3-07 ● 22.5 142 88 67.5 +1.0 DRC -DRX230M-3-07 ● 23 144 90 69 +0.9 -DRX235M-3-07 ● 23.5 145 91 70.5 +0.8 DRX -DRX240M-3-07 ● 2 24 147 93 72 25 33 +0.7 SB-2570TR DTM-8 ZXMT070305 U U -DRX245M-3-07 ● 24.5 148 94 73.5 +0.5 DRS -DRX250M-3-07 ● 25 150 96 75 +0.4 -DRX255M-3-07 ● 25.5 151 97 76.5 +0.3 DRZ -DRX260M-3-07 ● 26 153 99 78 +0.2 S32 -DRX265M-3-09 ● 26.5 161 102 79.5 +1.7 -DRX270M-3-09 ● 27 163 104 81 +1.6 DRW -DRX275M-3-09 ● 27.5 164 105 82.5 +1.5 -DRX280M-3-09 ● 28 166 107 84 41 +1.3 -DRX285M-3-09 ● 28.5 167 108 85.5 +1.2 -DRX290M-3-09 ● 2 29 169 110 87 32 +1.1 SB-3080TR DTM-10 ZXMT09T306 U U -DRX295M-3-09 ● 29.5 170 111 88.5 +1.1 -DRX300M-3-09 ● 30 172 113 90 +0.8 -DRX305M-3-09 ● 30.5 173 114 91.5 43 +0.7 -DRX310M-3-09 ● 31 175 116 93 +0.6 -DRX315M-3-09 ● 31.5 176 117 94.5 +0.5 S40 -DRX320M-3-11 ● 32 201 132 96 +2.2 -DRX330M-3-11 ● 33 204 135 99 +1.9 -DRX340M-3-11 ● 34 207 138 102 +1.7 -DRX350M-3-11 ● 2 35 210 141 105 40 54 +1.4 SB-4085TR DTM-15 ZXMT11T306 U U -DRX360M-3-11 ● 36 213 144 108 +1.2 -DRX370M-3-11 ● 37 216 147 111 +0.9 -DRX380M-3-11 ● 38 219 150 114 +0.7 ·When offset drilling, reduce feed rate to 0.08mm/rev or less. Recommended Cutting Conditions K48 ·Ref. to page K49 for Adjustable Sleeve (SHE type). Trouble shooting K47  : Std. Item K42
