MIKRO BOHRER / LINKSSCHNEIDEND
MICRO FORET / COUPE A GAUCHE
MICRO PUNTE / ESECUZIONE SINISTRA
D ℓ
L
1
L
MICRO L 2
GRAIN 130° Standard Length | Standardlänge | Longueur Standard | Lunghezza Standard
d h6
4 Facet Point Geometry
| D (mm) +0/-0.008 | ℓ (mm) | L1(mm) | d (mm) h6 | L (mm) | Art. No. (uncoated) | Art. No. (AlTiN coated) |
| 0.73 | 10.2 | 10.4 | 3 | 38 | 226L-0287.400 | 226L-0287L400 |
| 0.74 | 10.2 | 10.4 | 3 | 38 | 226L-0291.400 | 226L-0291L400 |
| 0.75 | 10.2 | 10.4 | 3 | 38 | 226L-0295.400 | 226L-0295L400 |
| 0.76 | 10.2 | 10.4 | 3 | 38 | 226L-0299.400 | 226L-0299L400 |
| 0.77 | 10.2 | 10.4 | 3 | 38 | 226L-0303.400 | 226L-0303L400 |
| 0.78 | 10.2 | 10.4 | 3 | 38 | 226L-0307.400 | 226L-0307L400 |
| 0.79 | 10.2 | 10.4 | 3 | 38 | 226L-0311.400 | 226L-0311L400 |
| 0.80 | 10.2 | 10.4 | 3 | 38 | 226L-0315.400 | 226L-0315L400 |
| 0.81 | 10.2 | 10.4 | 3 | 38 | 226L-0319.400 | 226L-0319L400 |
| 0.82 | 10.2 | 10.4 | 3 | 38 | 226L-0323.400 | 226L-0323L400 |
| 0.83 | 10.2 | 10.4 | 3 | 38 | 226L-0327.400 | 226L-0327L400 |
| 0.84 | 10.2 | 10.4 | 3 | 38 | 226L-0331.400 | 226L-0331L400 |
| 0.85 | 10.2 | 10.4 | 3 | 38 | 226L-0335.400 | 226L-0335L400 |
| 0.86 | 10.2 | 10.4 | 3 | 38 | 226L-0339.400 | 226L-0339L400 |
| 0.87 | 10.2 | 10.4 | 3 | 38 | 226L-0343.400 | 226L-0343L400 |
| 0.88 | 10.2 | 10.4 | 3 | 38 | 226L-0346.400 | 226L-0346L400 |
| 0.89 | 10.2 | 10.4 | 3 | 38 | 226L-0350.400 | 226L-0350L400 |
| 0.90 | 10.2 | 10.4 | 3 | 38 | 226L-0354.400 | 226L-0354L400 |
| 0.91 | 10.2 | 10.4 | 3 | 38 | 226L-0358.400 | 226L-0358L400 |
| 0.92 | 10.2 | 10.4 | 3 | 38 | 226L-0362.400 | 226L-0362L400 |
| 0.93 | 10.2 | 10.4 | 3 | 38 | 226L-0366.400 | 226L-0366L400 |
| 0.94 | 10.2 | 10.4 | 3 | 38 | 226L-0370.400 | 226L-0370L400 |
| 0.95 | 10.2 | 10.4 | 3 | 38 | 226L-0374.400 | 226L-0374L400 |
| 0.96 | 10.2 | 10.4 | 3 | 38 | 226L-0378.400 | 226L-0378L400 |
| 0.97 | 10.2 | 10.4 | 3 | 38 | 226L-0382.400 | 226L-0382L400 |
| 0.98 | 10.2 | 10.4 | 3 | 38 | 226L-0386.400 | 226L-0386L400 |
| 0.99 | 10.2 | 10.4 | 3 | 38 | 226L-0390.400 | 226L-0390L400 |
| 1.00 | 10.2 | 10.4 | 3 | 38 | 226L-0394.400 | 226L-0394L400 |
| 1.05 | 10.2 | 10.4 | 3 | 38 | 226L-0413.400 | 226L-0413L400 |
| 1.10 | 10.2 | 10.4 | 3 | 38 | 226L-0433.400 | 226L-0433L400 |
| 1.15 | 10.2 | 10.4 | 3 | 38 | 226L-0453.400 | 226L-0453L400 |
| 1.20 | 10.2 | 10.4 | 3 | 38 | 226L-0472.400 | 226L-0472L400 |
| 1.25 | 10.2 | 10.4 | 3 | 38 | 226L-0492.400 | 226L-0492L400 |
| 1.30 | 10.2 | 10.4 | 3 | 38 | 226L-0512.400 | 226L-0512L400 |
| 1.35 | 10.2 | 10.4 | 3 | 38 | 226L-0531.400 | 226L-0531L400 |
| 1.40 | 10.2 | 10.4 | 3 | 38 | 226L-0551.400 | 226L-0551L400 |
| 1.45 | 10.2 | 10.4 | 3 | 38 | 226L-0571.400 | 226L-0571L400 |
| 1.50 | 10.2 | 10.4 | 3 | 38 | 226L-0591.400 | 226L-0591L400 |
| 1.55 | 10.2 | 10.4 | 3 | 38 | 226L-0610.400 | 226L-0610L400 |
Coating
| Steel | Steel | Hardened Steel | Hardened Steel | Stainless | Cast Iron | Graphite | Copper | CFRP | Plastic | Thermoset | High Density | Nickel / | Titanium | ||
| ~30HRC | 30~40HRC | ~55HRC | ~68HRC | Steel | Aluminum | Alloy | Plastic | Plastic | Cobalt | Alloy | |||||
| AlTiN | ★ | ★ | ★ | ★ | ★ | ☆ | ☆ | ☆ | ☆ | ☆ | ☆ | ☆ | ☆ | ☆ |
