• Primary P • • Secondary M • K • N • S • H Beyond™ Evolution™ Grooving Inserts KCU10B GUN Precision Molded • METRIC W W tol ± RR LI Catalog Number Seat Size mm in mm in mm in mm in EG063I1FU05GUN 1F 1,600 .063 0,050 .002 0,20 .008 9,00 .355 • EG094I02U05GUN 2 2,388 .094 0,050 .002 0,20 .008 8,97 .353 • EG125I03U05GUN 3 3,175 .125 0,075 .003 0,20 .008 9,60 .378 • EG125I03U1GUN 3 3,175 .125 0,075 .003 0,40 .016 9,60 .378 • EG130I03U05GUN 3 3,302 .130 0,075 .003 0,20 .008 9,60 .378 • EG130I03U1GUN 3 3,302 .130 0,075 .003 0,40 .016 9,60 .378 • EG187I04U1GUN 4 4,750 .187 0,075 .003 0,40 .016 10,20 .401 • EG187I04U2GUN 4 4,750 .187 0,075 .003 0,80 .032 10,19 .401 • EG192I04U1GUN 4 4,877 .192 0,075 .003 0,40 .016 10,19 .401 • EG192I04U2GUN 4 4,878 .192 0,075 .003 0,79 .031 10,19 .401 • EG250I06U1GUN 6 6,350 .250 0,075 .003 0,40 .016 14,58 .574 • EG250I06U2GUN 6 6,350 .250 0,075 .003 0,80 .032 14,58 .574 • EG255I06U2GUN 6 6,477 .255 0,075 .003 0,80 .031 14,58 .574 • EG312I08U3GUN 8 7,925 .312 0,075 .003 1,20 .047 17,46 .687 • EG317I08U3GUN 8 8,052 .317 0,075 .003 1,19 .047 17,46 .687 • EG375I10U3GUN 10 9,525 .375 0,075 .003 1,20 .047 20,80 .817 • • Primary P • • Secondary M • K • N • S • H Beyond™ Evolution™ Grooving Inserts GUN Full Radius Precision Molded • INCH KCU10B W W tol ± RR LI Catalog Number Seat Size mm in mm in mm in mm in ER094I02U00GUN 2 2,387 .094 0,050 .002 1,190 .05 8,97 .353 • ER125I03U00GUN 3 3,177 .125 0,075 .003 1,590 .06 9,60 .378 • ER130I03U00GUN 3 3,300 .130 0,075 .003 1,650 .07 9,60 .378 • ER187I04U00GUN 4 4,750 .187 0,075 .003 2,370 .09 10,20 .400 • ER192I04U00GUN 4 4,873 .192 0,075 .003 2,440 .10 10,20 .401 • ER250I06U00GUN 6 6,346 .250 0,075 .003 3,170 .13 14,60 .575 • ER312I08U00GUN 8 7,925 .312 0,075 .003 3,960 .16 17,50 .688 • ER317I08U00GUN 8 8,052 .317 0,075 .003 4,030 .16 17,50 .688 • 50
