• Primary P • • Secondary M K • • N S H Dodeka™ KCK20B KCKP10 ANSI ISO D BS L10 Rε S Cutting Order # Catalog # Catalog # mm in mm in mm in mm in mm in Edges 6970342 HNPJ0905ANSNHD HNPJ535ANSNHD 15.88 0.625 1.65 0.065 8.59 0.338 1.2 0.047 5.46 0.215 12 • - 6970341 HNGJ0905ANSNHD HNGJ535ANSNHD 15.88 0.625 1.65 0.065 8.59 0.338 1.2 0.047 5.46 0.215 12 • - 6970344 HNGJ090543ANSNHD HNGJ53511ANSNHD 15.88 0.625 - - 8.50 0.335 4.4 0.171 5.44 0.214 12 • - 6970328 HNGJ0905ANENLD HNGJ535ANENLD 15.88 0.625 1.76 0.069 8.58 0.338 1.2 0.047 5.56 0.219 12 • - 6970329 HNPJ0905ANSNGD HNPJ535ANSNGD 15.88 0.625 1.80 0.071 8.58 0.338 1.2 0.047 5.56 0.219 12 • - • Primary P • • Secondary M K • • N S H Mill 16™ KCK20B KCKP10 ANSI ISO D S L10 BS Rε Cutting Order # Catalog # Catalog # mm in mm in mm in mm in mm in Edges 6969272 ONGX0806ANSNGP ONGX64ANSNGP 20.00 0.787 5.81 0.229 8.21 0.323 1.50 0.059 0.8 0.031 16 • - 6969279 ONGX080620SNGP ONGX645SNGP 20.00 0.787 5.81 0.229 8.28 0.326 - - 2.0 0.079 16 • - 6969273 ONGX080620SNHB ONGX645SNHB 20.00 0.787 5.81 0.229 8.28 0.326 - - 2.0 0.079 16 • - 6969278 ONGX080630SNHB ONGX648SNHB 20.00 0.787 5.81 0.229 8.28 0.326 - - 3.0 0.118 16 • - 6969274 ONGX0806ANENLE ONGX64ANENLE 20.00 0.787 5.81 0.229 8.21 0.323 1.50 0.059 0.8 0.031 16 • - 6969280 ONGX080620ENLE ONGX645ENLE 20.00 0.787 5.81 0.229 8.28 0.326 - - 2.0 0.079 16 • - 6969277 ONPX080620SNHB ONPX645SNHB 20.00 0.787 5.81 0.229 8.28 0.326 - - 2.0 0.079 16 • - 6969263 ONPX080608SNGP ONPX642SNGP 20.00 0.787 5.81 0.229 8.28 0.326 - - 0.8 0.032 16 • - 7
