Сменные фрезерные пластины сплавов KCK20B и KCKP10 Kennametal 2024 - страница 13

• Primary P • • Secondary M K • • N S H CN Slotting KCK20B KCKP10 ISO ANSI LI W S Rε Cutting Order # Catalog # Catalog # mm in mm in mm in mm in Edges 6993268 CNHU1606R08 CNHU1606R08 16.00 0.630 12.06 0.475 6.40 0.252 0.8 0.031 2 • - 6993269 CNHU1205R08 CNHU1205R08 12.70 0.500 10.06 0.396 5.40 0.213 0.8 0.031 2 • - 6993270 CNHU1005R08 CNHU1005R08 10.00 0.394 10.06 0.396 5.40 0.213 0.8 0.031 2 • - 6993271 CNHU1005R16 CNHU1005R16 10.00 0.394 10.06 0.396 5.40 0.213 1.6 0.063 2 • - 6993272 CNHU1606R16 CNHU1606R16 16.00 0.630 12.06 0.475 6.40 0.252 1.6 0.063 2 • - 6993273 CNHU1205R16 CNHU1205R16 12.70 0.500 10.06 0.396 5.40 0.213 1.6 0.063 2 • - Speed m/min Speed SFM Material Group KCKP10 KCK20B Material Group KCKP10 KCK20B Chip Thickness hex mm Min Max Min Max Chip Thickness hex in Min Max Min Max Cutting Speed (m/min) Max Start Min Max Start Min Cutting Speed (m/min) Max Start Min Max Start Min 1 300 295 260 – – – 1 985 970 855 – – – 2 310 275 240 – – – 2 1015 900 785 – – – 3 275 240 205 – – – 3 900 785 675 – – – P P 4 240 205 160 – – – 4 785 675 525 – – – 5 205 160 125 – – – 5 675 525 410 – – – 6 160 125 110 – – – 6 525 410 360 – – – 1 410 330 240 360 290 245 1 1345 1085 785 1180 950 805 K 2 280 245 190 280 230 195 K 2 920 805 625 920 755 640 3 240 195 160 210 175 140 3 785 640 525 690 575 460 1 140 110 90 – – – 1 460 360 295 – – – H 2 – – – – – – H 2 – – – – – – 3 – – – – – – 3 – – – – – – Recommended starting speeds are bolded. As the average chip thickness increases, speed should be decreased. Material groups P, K and H show recommended starting speeds for dry machining. For wet machining, reduce speed by 20%. Recommended starting speeds are pointing to 90° shoulder milling. Starting speeds for face and copy milling can be increased by 20%. 13
