(B966A/B967A • ~3 x D/~5 x D — продолжение)
лучший выбор альтернативный выбор диаметр D1
| минимальный • KC7315 | удлиненное • KC7315 | мм | дюйм | L5 | LS | D | |||||||||
| B966A06300 | – | 6,300 | .2480 | 1,1 | 36 | 8 | |||||||||
| B966A06350 | – | 6,350 | .2500 | 1,1 | 36 | 8 | |||||||||
| B966A06400 | – | 6,400 | .2520 | 1,1 | 36 | 8 | |||||||||
| B966A06500 | B967A06500 | 6,500 | .2559 | 1,1 | 36 | 8 | |||||||||
| B966A06600 | B967A06600 | 6,600 | .2598 | 1,1 | 36 | 8 | |||||||||
| Значения L, L3 и L4 max приведены в таблице размеров | |||||||||||||||
| Цельные твердосплавные сверла на вкладке. | B966A06700 | B967A06700 | 6,700 | .2638 | 1,1 | 36 | 8 | ||||||||
| B966A06800 | B967A06800 | 6,800 | .2677 | 1,1 | 36 | 8 | |||||||||
| B966A06900 | – | 6,900 | .2717 | 1,2 | 36 | 8 | |||||||||
| B966A/B967A • ~3 x D/~5 x D | B966A07000 | B967A07000 | 7,000 | .2756 | 1,2 | 36 | 8 | ||||||||
| B966A07100 | – | 7,100 | .2795 | 1,2 | 36 | 8 | |||||||||
| B966A07200 | – | 7,200 | .2835 | 1,2 | 36 | 8 | |||||||||
| B966A07300 | – | 7,300 | .2874 | 1,2 | 36 | 8 | |||||||||
| лучший выбор | |||||||||||||||
| B966A07400 | B967A07400 | 7,400 | .2913 | 1,3 | 36 | 8 | |||||||||
| альтернативный выбор | |||||||||||||||
| B966A07500 | B967A07500 | 7,500 | .2953 | 1,3 | 36 | 8 | |||||||||
| диаметр D1 | |||||||||||||||
| B966A07600 | – | 7,600 | .2992 | 1,3 | 36 | 8 | |||||||||
| B966A07700 | – | 7,700 | .3031 | 1,3 | 36 | 8 | |||||||||
| минимальный • KC7315 | удлиненное • KC7315 | мм | дюйм | L5 | LS | D | B966A07800 | B967A07800 | 7,800 | .3071 | 1,3 | 36 | 8 | ||
| B966A03000 | B967A03000 | 3,000 | .1181 | 0,5 | 36 | 6 | B966A07900 | – | 7,900 | .3110 | 1,3 | 36 | 8 | ||
| B966A03100 | B967A03100 | 3,100 | .1220 | 0,5 | 36 | 6 | B966A08000 | B967A08000 | 8,000 | .3150 | 1,4 | 36 | 8 | ||
| B966A03200 | B967A03200 | 3,200 | .1260 | 0,5 | 36 | 6 | B966A08100 | B967A08100 | 8,100 | .3189 | 1,4 | 40 | 10 | ||
| B966A03300 | B967A03300 | 3,300 | .1299 | 0,5 | 36 | 6 | B966A08200 | – | 8,200 | .3228 | 1,4 | 40 | 10 | ||
| B966A03400 | – | 3,400 | .1339 | 0,6 | 36 | 6 | B966A08300 | – | 8,300 | .3268 | 1,4 | 40 | 10 | ||
| B966A03500 | B967A03500 | 3,500 | .1378 | 0,6 | 36 | 6 | B966A08400 | – | 8,400 | .3307 | 1,4 | 40 | 10 | ||
| B966A03600 | – | 3,600 | .1417 | 0,6 | 36 | 6 | B966A08500 | B967A08500 | 8,500 | .3346 | 1,4 | 40 | 10 | ||
| B966A03700 | – | 3,700 | .1457 | 0,6 | 36 | 6 | B966A08600 | B967A08600 | 8,600 | .3386 | 1,5 | 40 | 10 | ||
| B966A03800 | B967A03800 | 3,800 | .1496 | 0,6 | 36 | 6 | B966A08700 | B967A08700 | 8,700 | .3425 | 1,5 | 40 | 10 | ||
| B966A03900 | – | 3,900 | .1535 | 0,6 | 36 | 6 | B966A08800 | B967A08800 | 8,800 | .3465 | 1,5 | 40 | 10 | ||
| B966A03960 | – | 3,960 | .1559 | 0,7 | 36 | 6 | B966A08900 | – | 8,900 | .3504 | 1,5 | 40 | 10 | ||
| B966A04000 | B967A04000 | 4,000 | .1575 | 0,7 | 36 | 6 | B966A09000 | B967A09000 | 9,000 | .3543 | 1,5 | 40 | 10 | ||
| B966A04100 | – | 4,100 | .1614 | 0,7 | 36 | 6 | B966A09100 | – | 9,100 | .3583 | 1,5 | 40 | 10 | ||
| B966A04200 | B967A04200 | 4,200 | .1654 | 0,7 | 36 | 6 | B966A09200 | – | 9,200 | .3622 | 1,6 | 40 | 10 | ||
| B966A04300 | B967A04300 | 4,300 | .1693 | 0,7 | 36 | 6 | B966A09300 | B967A09300 | 9,300 | .3661 | 1,6 | 40 | 10 | ||
| B966A04400 | – | 4,400 | .1732 | 0,7 | 36 | 6 | B966A09400 | – | 9,400 | .3701 | 1,6 | 40 | 10 | ||
| B966A04500 | B967A04500 | 4,500 | .1772 | 0,7 | 36 | 6 | B966A09500 | B967A09500 | 9,500 | .3740 | 1,6 | 40 | 10 | ||
| B966A04600 | – | 4,600 | .1811 | 0,8 | 36 | 6 | B966A09600 | – | 9,600 | .3780 | 1,6 | 40 | 10 | ||
| B966A04700 | – | 4,700 | .1850 | 0,8 | 36 | 6 | B966A09700 | – | 9,700 | .3819 | 1,7 | 40 | 10 | ||
| B966A04800 | B967A04800 | 4,800 | .1890 | 0,8 | 36 | 6 | B966A09800 | B967A09800 | 9,800 | .3858 | 1,7 | 40 | 10 | ||
| B966A04900 | – | 4,900 | .1929 | 0,8 | 36 | 6 | B966A09900 | – | 9,900 | .3898 | 1,7 | 40 | 10 | ||
| B966A05000 | B967A05000 | 5,000 | .1969 | 0,8 | 36 | 6 | B966A10000 | B967A10000 | 10,000 | .3937 | 1,7 | 40 | 10 | ||
| B966A05040 | – | 5,040 | .1984 | 0,8 | 36 | 6 | B966A10100 | – | 10,100 | .3976 | 1,7 | 45 | 12 | ||
| B966A05100 | B967A05100 | 5,100 | .2008 | 0,8 | 36 | 6 | B966A10200 | B967A10200 | 10,200 | .4016 | 1,7 | 45 | 12 | ||
| B966A05200 | B967A05200 | 5,200 | .2047 | 0,9 | 36 | 6 | B966A10300 | – | 10,300 | .4055 | 1,8 | 45 | 12 | ||
| B966A05300 | – | 5,300 | .2087 | 0,9 | 36 | 6 | B966A10400 | – | 10,400 | .4094 | 1,8 | 45 | 12 | ||
| B966A05400 | – | 5,400 | .2126 | 0,9 | 36 | 6 | B966A10500 | B967A10500 | 10,500 | .4134 | 1,8 | 45 | 12 | ||
| B966A05500 | B967A05500 | 5,500 | .2165 | 0,9 | 36 | 6 | B966A10600 | – | 10,600 | .4173 | 1,8 | 45 | 12 | ||
| B966A05600 | – | 5,600 | .2205 | 0,9 | 36 | 6 | B966A10700 | B967A10700 | 10,700 | .4213 | 1,8 | 45 | 12 | ||
| B966A05700 | – | 5,700 | .2244 | 1,0 | 36 | 6 | B966A10800 | B967A10800 | 10,800 | .4252 | 1,8 | 45 | 12 | ||
| B966A05800 | B967A05800 | 5,800 | .2283 | 1,0 | 36 | 6 | B966A10900 | – | 10,900 | .4291 | 1,9 | 45 | 12 | ||
| B966A05900 | – | 5,900 | .2323 | 1,0 | 36 | 6 | B966A11000 | B967A11000 | 11,000 | .4331 | 1,9 | 45 | 12 | ||
| B966A06000 | B967A06000 | 6,000 | .2362 | 1,0 | 36 | 6 | B966A11100 | – | 11,100 | .4370 | 1,9 | 45 | 12 | ||
| B966A06050 | – | 6,050 | .2382 | 1,0 | 36 | 8 | B966A11200 | – | 11,200 | .4409 | 1,9 | 45 | 12 | ||
| B966A06100 | B967A06100 | 6,100 | .2402 | 1,0 | 36 | 8 | B966A11300 | B967A11300 | 11,300 | .4449 | 1,9 | 45 | 12 | ||
| B966A06200 | – | 6,200 | .2441 | 1,0 | 36 | 8 |
