P P M M
| лучший выбор | K | лучший выбор | K |
| альтернативный выбор | N | альтернативный выбор | N |
S S H H
- WNGG-FS
- WNMA
Номер по Номер по
| каталогу ISO | D | L10 | R | каталогу ISO | D | L10 | R | |||||
| WNGG080404FS | 12,70 | 8,69 | 0,4 | – – – – – – – – – – – – – – – – – – – – – – – – – | – – – – – | WNMA060408 | 9,53 | 6,52 | 0,8 | – – – – – – – – – – – – – | – – – – – – – – – – – – – – – – – | |
| WNGG080408FS | 12,70 | 8,69 | 0,8 | – – – – – – – – – – – – – – – – – – – – – – – – – | – – – – – | WNMA060412 | 9,53 | 6,52 | 1,2 | – – – – – – – – – – – – – – | – – – – – – – – – – – – – – – | |
| WNMA080408 | 12,70 | 8,69 | 0,8 | – – – – – – – – – – – | – | – – – – – – – – – – – – – – – | ||||||
| WNMA080412 | 12,70 | 8,69 | 1,2 | – – – – – – – – – – – – | – | – – – – – – – – – – – – – – – | ||||||
| WNMA080416 | 12,70 | 8,69 | 1,6 | – – – – – – – – – – – – – – – | – – – – – – – – – – – – – – – |
- WNGG-LF
Номер по
| каталогу ISO | D | L10 | R | |||
| WNGG080401LF | 12,70 | 8,69 | 0,1 | – – – – – – – – – – – – – – – – – – – – – – – – – – – | – – – | |
| WNGG080402LF | 12,70 | 8,69 | 0,2 | – – – – – – – – – – – – – – – – – – – – – – – – – | – | – – – |
| WNGG080404LF | 12,70 | 8,69 | 0,4 | – – – – – – – – – – – – – – – – – – – – – – – – – | – | – – – |
| WNGG080408LF | 12,70 | 8,69 | 0,8 | – – – – – – – – – – – – – – – – – – – – – – – – – – – | – – – |
- WNMG-FF
Номер по
| каталогу ISO | D | L10 | R | ||||
| WNMG060404FF | 9,53 | 6,52 | 0,4 | – – – | – – – – – – – – – – – – – – – – – – – – – | – – – – – | |
| WNMG060408FF | 9,53 | 6,52 | 0,8 | – – – | – – – – – – – – – – – – – – – – – – – – – – – | – – | |
| WNMG080404FF | 12,70 | 8,69 | 0,4 | – – – | – – – – – – – – – – – – – – – – – – – – – | – | – – – |
| WNMG080408FF | 12,70 | 8,69 | 0,8 | – – – | – – – – – – – – – – – – – – – – – – – – – – – | – – – |
- WNGP-K
Номер по
| каталогу ISO | D | L10 | R |
| WNGP080408K | 12,70 | 8,69 | 0,8 |
- WNMG-FN
Номер по
| каталогу ISO | D | L10 | R | ||||||
| WNMG060404FN | 9,53 | 6,52 | 0,4 | – – – | – – – – – – – | – – – – – – – – – – – – – – – – – – | |||
| WNMG060408FN | 9,53 | 6,52 | 0,8 | – – – | – | – – – – – – | – – – – – – – – – – – – – – – – – | ||
| WNMG080404FN | 12,70 | 8,69 | 0,4 | – | – – – – – | – – – – – – – – – – – – – – – – – – | |||
| WNMG080408FN | 12,70 | 8,69 | 0,8 | – | – – – – – | – – – – – – – – – – – – – – – – – |
