лучший выбор альтернативный выбор
P P M M
| K | лучший выбор | K |
| N | альтернативный выбор | N |
S S H H
- VNMG-MP
- VNMG-RN
Номер по Номер по
| каталогу ISO | D | L10 | R | каталогу ISO | D | L10 | R | |||||||||||
| VNMG160404MP | 9,53 | 16,61 | 0,4 | – – – – – – – – – – – – – – – – | – | – – – | – | – – – | VNMG160408RN | 9,53 | 16,61 | 0,8 | – – | – – – – – – – – – – – – – – – – – – – – – – – – – | ||||
| VNMG160408MP | 9,53 | 16,61 | 0,8 | – – – – – – – – – – – – – – – – | – | – – – | – | – – – | VNMG160412RN | 9,53 | 16,61 | 1,2 | – – – | – – – – – – – – – – – – – – – – – – – – – – – – – | ||||
| VNMG160412MP | 9,53 | 16,61 | 1,2 | – – – – – – – – – – – – – – – – | – – – – – – – – | – | – – – | VNMG220408RN | 12,70 | 22,14 | 0,8 | – – | – | – | – – – – – – – – – – – – – – – – – – – – – | |||
| VNMG220412RN | 12,70 | 22,14 | 1,2 | – – – | – | – | – – – – – – – – – – – – – – – – – – – – – – – |
- VNMG-MR
Номер по
| каталогу ISO | D | L10 | R |
| VNMG160412MR | 9,52 | 16,61 | 1,2 |
| VNMG160408MR | 9,53 | 16,61 | 0,8 |
- VNMG-RP
Номер по
| каталогу ISO | D | L10 | R | ||||||||||
| VNMG160408RP | 9,53 | 16,61 | 0,8 | – – – | – | – – – – – – – | – – | – – – – – – – | – – | ||||
| VNMG160412RP | 9,53 | 16,61 | 1,2 | – – – | – | – – – – – – | – | – – – | – – – – – | – – – – |
- VNMG-MS
Номер по
| каталогу ISO | D | L10 | R | ||||
| VNMG160401MS | 9,53 | 16,61 | 0,1 | – – – – – – – – – – – – – – – – – – – – – – – – – | – – – | ||
| VNMG160402MS | 9,53 | 16,61 | 0,2 | – – – – – – – – – – – – – – – – – – – – – – – | – | – – | |
| VNMG160404MS | 9,53 | 16,61 | 0,4 | – – – – – – – – – – – – – – – – – – – – – – – | – | – – | |
| VNMG160408MS | 9,53 | 16,61 | 0,8 | – – – – – – – – – – – – – – – – – – – – – – – | – | – – | |
| VNMG220404MS | 12,70 | 22,14 | 0,4 | – – – – – – – – – – – – – – – – – – – – – – – – – | – – – | ||
| VNMG220408MS | 12,70 | 22,14 | 0,8 | – – – – – – – – – – – – – – – – – – – – – – – – – | – – |
- VNMG-UN
Номер по
| каталогу ISO | D | L10 | R | ||||
| VNMG160404UN | 9,53 | 16,61 | 0,4 | – – – – – – – – – – – – – | – | – – – – – – – – – – – – – – – | |
| VNMG160408UN | 9,53 | 16,61 | 0,8 | – – – – – – – – – – | – | – | – – – – – – – – – – – – – – – |
- VNMG-P
Номер по
| каталогу ISO | D | L10 | R | ||||
| VNMG160404P | 9,53 | 16,61 | 0,4 | – – – – – – – – – – – – – – – – – – – – – – – – – | – | – – – | |
| VNMG160408P | 9,53 | 16,61 | 0,8 | – – – – – – – – – – – – – – – – – – – – – – – | – | – | – – – |
- VNMG-UP
Номер по
| каталогу ISO | D | L10 | R | |||||
| VNMG160404UP | 9,53 | 16,61 | 0,4 | – – – – – – – – – – – – – – – – – | – | – – – – – – – | – – – | |
| VNMG160408UP | 9,53 | 16,61 | 0,8 | – – – – – – – – – – – – – – – – – | – | – – – – – | – | – – – |
| VNMG160412UP | 9,53 | 16,61 | 1,2 | – – – – – – – – – – – – – – – – – | – – – – – – – – – – – – – |
