СБОРНАЯ СИСТЕМА СВЕРЛЕНИЯ DRILL FIX PRO
Корпус сверла • 2xD • Державка WB
Более компактный диаметр державки
| Номер заказа | Артикул | D1 | D1 Макс | L5 | L1 | L4 Макс | LS | D | CS | Пластина 1 Наружная | Пластина 2 Внутренняя |
| 7214601 | DFPR265R2WB32M | 26,50 | 27,50 | 0,78 | 77,00 | 53,00 | 60,00 | 32,00 | 1/4-18 NPT | DFPR090305__O | DFPR100305__I |
| 7214527 | DFPR450R2WB40M | 45,00 | 46,00 | 1,50 | 116,00 | 90,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR140408__O | DFPR140406__I |
| 7214769 | DFPR460R2WB40M | 46,00 | 47,00 | 1,20 | 120,00 | 92,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR150508__O | DFPR170508__I |
| 7214770 | DFPR470R2WB40M | 47,00 | 48,00 | 1,28 | 122,00 | 94,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR150508__O | DFPR170508__I |
| 7214811 | DFPR480R2WB40M | 48,00 | 49,00 | 1,36 | 125,00 | 96,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR150508__O | DFPR170508__I |
| 7214812 | DFPR490R2WB40M | 49,00 | 50,00 | 1,44 | 126,00 | 98,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR150508__O | DFPR170508__I |
| 7214813 | DFPR500R2WB40M | 50,00 | 51,00 | 1,52 | 128,00 | 100,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR150508__O | DFPR170508__I |
| 7214814 | DFPR510R2WB40M | 51,00 | 52,00 | 1,60 | 132,00 | 102,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR150508__O | DFPR170508__I |
| 7214815 | DFPR520R2WB40M | 52,00 | 53,00 | 1,69 | 134,00 | 104,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR150508__O | DFPR170508__I |
| 7214816 | DFPR530R2WB40M | 53,00 | 54,00 | 1,77 | 136,00 | 106,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR150508__O | DFPR170508__I |
| 7214817 | DFPR540R2WB40M | 54,00 | 55,00 | 1,85 | 138,00 | 108,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR150508__O | DFPR170508__I |
| 7214653 | DFPR550R2WB40M | 55,00 | 56,00 | 1,37 | 142,00 | 110,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR180610__O | DFPR200608__I |
| 7214654 | DFPR560R2WB40M | 56,00 | 57,00 | 1,45 | 144,00 | 112,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR180610__O | DFPR200608__I |
| 7214655 | DFPR570R2WB40M | 57,00 | 58,00 | 1,53 | 146,00 | 114,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR180610__O | DFPR200608__I |
| 7214656 | DFPR580R2WB40M | 58,00 | 59,00 | 1,61 | 148,00 | 116,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR180610__O | DFPR200608__I |
| 7214657 | DFPR590R2WB40M | 59,00 | 60,00 | 1,70 | 152,00 | 118,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR180610__O | DFPR200608__I |
| 7214659 | DFPR600R2WB40M | 60,00 | 61,00 | 1,78 | 154,00 | 120,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR180610__O | DFPR200608__I |
| 7214660 | DFPR610R2WB40M | 61,00 | 62,00 | 1,86 | 156,00 | 122,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR180610__O | DFPR200608__I |
| 7214671 | DFPR620R2WB40M | 62,00 | 63,00 | 1,94 | 158,00 | 124,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR180610__O | DFPR200608__I |
| 7214672 | DFPR630R2WB40M | 63,00 | 64,00 | 2,02 | 161,00 | 126,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR180610__O | DFPR200608__I |
| 7214673 | DFPR640R2WB40M | 64,00 | 65,00 | 2,10 | 163,00 | 128,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR180610__O | DFPR200608__I |
| 7214674 | DFPR650R2WB40M | 65,00 | 66,00 | 2,19 | 165,00 | 130,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR180610__O | DFPR200608__I |
Корпус сверла • 3xD • Державка WB
Более компактный диаметр державки
| Номер заказа | Артикул | D1 | D1 Макс | L5 | L1 | L4 Макс | LS | D | CS | Пластина 1 Наружная | Пластина 2 Внутренняя |
| 7214602 | DFPR265R3WB32M | 26,50 | 27,50 | 0,78 | 103,50 | 79,50 | 60,00 | 32,00 | 1/4-18 NPT | DFPR090305__O | DFPR100305__I |
| 7214528 | DFPR450R3WB40M | 45,00 | 46,00 | 1,50 | 161,00 | 135,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR140408__O | DFPR140406__I |
| 7214818 | DFPR460R3WB40M | 46,00 | 47,00 | 1,20 | 166,00 | 138,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR150508__O | DFPR170508__I |
| 7214819 | DFPR470R3WB40M | 47,00 | 48,00 | 1,28 | 169,00 | 141,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR150508__O | DFPR170508__I |
| 7214820 | DFPR480R3WB40M | 48,00 | 49,00 | 1,36 | 173,00 | 144,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR150508__O | DFPR170508__I |
| 7214821 | DFPR490R3WB40M | 49,00 | 50,00 | 1,44 | 175,00 | 147,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR150508__O | DFPR170508__I |
| 7214822 | DFPR500R3WB40M | 50,00 | 51,00 | 1,52 | 178,00 | 150,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR150508__O | DFPR170508__I |
| 7214823 | DFPR510R3WB40M | 51,00 | 52,00 | 1,60 | 183,00 | 153,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR150508__O | DFPR170508__I |
| 7214824 | DFPR520R3WB40M | 52,00 | 53,00 | 1,69 | 186,00 | 156,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR150508__O | DFPR170508__I |
| 7214825 | DFPR530R3WB40M | 53,00 | 54,00 | 1,77 | 189,00 | 159,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR150508__O | DFPR170508__I |
| 7214826 | DFPR540R3WB40M | 54,00 | 55,00 | 1,85 | 192,00 | 162,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR150508__O | DFPR170508__I |
| 7214675 | DFPR550R3WB40M | 55,00 | 56,00 | 1,37 | 197,00 | 165,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR180610__O | DFPR200608__I |
| 7214676 | DFPR560R3WB40M | 56,00 | 57,00 | 1,45 | 200,00 | 200,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR180610__O | DFPR200608__I |
| 7214678 | DFPR570R3WB40M | 57,00 | 58,00 | 1,53 | 203,00 | 203,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR180610__O | DFPR200608__I |
| 7214679 | DFPR580R3WB40M | 58,00 | 59,00 | 1,61 | 206,00 | 174,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR180610__O | DFPR200608__I |
| 7214680 | DFPR590R3WB40M | 59,00 | 60,00 | 1,70 | 211,00 | 177,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR180610__O | DFPR200608__I |
| 7214681 | DFPR600R3WB40M | 60,00 | 61,00 | 1,78 | 214,00 | 180,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR180610__O | DFPR200608__I |
| 7214683 | DFPR610R3WB40M | 61,00 | 62,00 | 1,86 | 217,00 | 183,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR180610__O | DFPR200608__I |
| 7214684 | DFPR620R3WB40M | 62,00 | 63,00 | 1,94 | 220,00 | 186,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR180610__O | DFPR200608__I |
| 7214685 | DFPR630R3WB40M | 63,00 | 64,00 | 2,02 | 224,00 | 189,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR180610__O | DFPR200608__I |
| 7214686 | DFPR640R3WB40M | 64,00 | 65,00 | 2,10 | 227,00 | 192,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR180610__O | DFPR200608__I |
| 7214687 | DFPR650R3WB40M | 65,00 | 66,00 | 2,19 | 230,00 | 195,00 | 70,00 | 40,00 | 1/4-18 NPT | DFPR180610__O | DFPR200608__I |
