TopSwiss MBS INSERTS
Расточка и профилирование (Продолжение)
ВП • Высокая производительность
| Номер заказа | Каталоговый номер | D | DMIN (дюйм) | DMIN (мм) | L4 (дюйм) | L4 (мм) | L (дюйм) | L (мм) | R (дюйм) | R (мм) | Угол наклона | Задний угол | Применение |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 7232894 | R4BPHP010H05R005 KCPM25S | 4 | 0.039 | 1.00 | 0.197 | 5 | 0.787 | 20 | 0.002 | 0.05 | 6.0° | 7.0° | • |
| 7232895 | R4BPHP015H07R010 KCPM25S | 4 | 0.059 | 1.50 | 0.276 | 7 | 0.827 | 21 | 0.004 | 0.10 | 6.0° | 7.0° | • |
| 7232896 | R4BPHP020H05R015 KCPM25S | 4 | 0.079 | 2.00 | 0.197 | 5 | 0.748 | 19 | 0.006 | 0.15 | 6.0° | 7.0° | • |
| 7232897 | R4BPHP020H10R005 KCPM25S | 4 | 0.079 | 2.00 | 0.394 | 10 | 0.945 | 24 | 0.002 | 0.05 | 6.0° | 7.0° | • |
| 7232898 | R4BPHP020H10R015 KCPM25S | 4 | 0.079 | 2.00 | 0.394 | 10 | 0.945 | 24 | 0.006 | 0.15 | 6.0° | 7.0° | • |
| 7232899 | R4BPHP020H15R015 KCPM25S | 4 | 0.079 | 2.00 | 0.591 | 15 | 1.142 | 29 | 0.006 | 0.15 | 6.0° | 7.0° | • |
| 7232900 | R4BPHP030H10R005 KCPM25S | 4 | 0.118 | 3.00 | 0.394 | 10 | 0.945 | 24 | 0.002 | 0.05 | 6.0° | 7.0° | • |
| 7232911 | R4BPHP030H10R020 KCPM25S | 4 | 0.118 | 3.00 | 0.394 | 10 | 0.945 | 24 | 0.008 | 0.20 | 6.0° | 7.0° | • |
| 7232912 | R4BPHP030H16R005 KCPM25S | 4 | 0.118 | 3.00 | 0.630 | 16 | 1.181 | 30 | 0.002 | 0.05 | 6.0° | 7.0° | • |
| 7232913 | R4BPHP030H16R010 KCPM25S | 4 | 0.118 | 3.00 | 0.630 | 16 | 1.181 | 30 | 0.004 | 0.10 | 6.0° | 7.0° | • |
| 7232914 | R4BPHP030H16R020 KCPM25S | 4 | 0.118 | 3.00 | 0.630 | 16 | 1.181 | 30 | 0.008 | 0.20 | 6.0° | 7.0° | • |
| 7232915 | R4BPHP040H10R010 KCPM25S | 4 | 0.158 | 4.00 | 0.394 | 10 | 0.945 | 24 | 0.004 | 0.10 | 6.0° | 7.0° | • |
| 7232916 | R4BPHP040H10R020 KCPM25S | 4 | 0.158 | 4.00 | 0.394 | 10 | 0.945 | 24 | 0.008 | 0.20 | 6.0° | 7.0° | • |
| 7232917 | R4BPHP040H16R005 KCPM25S | 4 | 0.158 | 4.00 | 0.630 | 16 | 1.181 | 30 | 0.002 | 0.05 | 6.0° | 7.0° | • |
| 7232918 | R4BPHP040H16R010 KCPM25S | 4 | 0.158 | 4.00 | 0.630 | 16 | 1.181 | 30 | 0.004 | 0.10 | 6.0° | 7.0° | • |
| 7232919 | R4BPHP040H16R020 KCPM25S | 4 | 0.158 | 4.00 | 0.630 | 16 | 1.181 | 30 | 0.008 | 0.20 | 6.0° | 7.0° | • |
| 7232920 | R4BPHP040H16R040 KCPM25S | 4 | 0.158 | 4.00 | 0.630 | 16 | 1.181 | 30 | 0.016 | 0.40 | 6.0° | 7.0° | • |
| 7232921 | R4BPHP040H24R010 KCPM25S | 4 | 0.158 | 4.00 | 0.945 | 24 | 1.496 | 38 | 0.004 | 0.10 | 6.0° | 7.0° | • |
| 7232922 | R4BPHP040H24R020 KCPM25S | 4 | 0.158 | 4.00 | 0.945 | 24 | 1.496 | 38 | 0.008 | 0.20 | 6.0° | 7.0° | • |
| 7232923 | R4BPHP040H24R040 KCPM25S | 4 | 0.158 | 4.00 | 0.945 | 24 | 1.496 | 38 | 0.016 | 0.40 | 6.0° | 7.0° | • |
| 7232924 | R5BPHP050H15R005 KCPM25S | 5 | 0.197 | 5.00 | 0.591 | 15 | 1.181 | 30 | 0.002 | 0.05 | 6.0° | 7.0° | • |
| 7232925 | R5BPHP050H15R010 KCPM25S | 5 | 0.197 | 5.00 | 0.591 | 15 | 1.181 | 30 | 0.004 | 0.10 | 6.0° | 7.0° | • |
| 7232926 | R5BPHP050H15R020 KCPM25S | 5 | 0.197 | 5.00 | 0.591 | 15 | 1.181 | 30 | 0.008 | 0.20 | 6.0° | 7.0° | • |
| 7232927 | R5BPHP050H15R040 KCPM25S | 5 | 0.197 | 5.00 | 0.591 | 15 | 1.181 | 30 | 0.016 | 0.40 | 6.0° | 7.0° | • |
| 7232928 | R5BPHP050H25R010 KCPM25S | 5 | 0.197 | 5.00 | 0.984 | 25 | 1.575 | 40 | 0.004 | 0.10 | 6.0° | 7.0° | • |
| 7232929 | R5BPHP050H25R020 KCPM25S | 5 | 0.197 | 5.00 | 0.984 | 25 | 1.575 | 40 | 0.008 | 0.20 | 6.0° | 7.0° | • |
| 7232930 | R5BPHP050H30R010 KCPM25S | 5 | 0.197 | 5.00 | 1.181 | 30 | 1.772 | 45 | 0.004 | 0.10 | 6.0° | 7.0° | • |
| 7232941 | R5BPHP050H30R020 KCPM25S | 5 | 0.197 | 5.00 | 1.181 | 30 | 1.772 | 45 | 0.008 | 0.20 | 6.0° | 7.0° | • |
| 7232942 | R5BPHP050H30R040 KCPM25S | 5 | 0.197 | 5.00 | 1.181 | 30 | 1.772 | 45 | 0.016 | 0.40 | 6.0° | 7.0° | • |
| 7232943 | R6BPHP060H15R005 KCPM25S | 6 | 0.236 | 6.00 | 0.591 | 15 | 1.181 | 30 | 0.002 | 0.05 | 6.0° | 7.0° | • |
| 7232944 | R6BPHP060H15R010 KCPM25S | 6 | 0.236 | 6.00 | 0.591 | 15 | 1.181 | 30 | 0.004 | 0.10 | 6.0° | 7.0° | • |
| 7232945 | R6BPHP060H15R020 KCPM25S | 6 | 0.236 | 6.00 | 0.591 | 15 | 1.181 | 30 | 0.008 | 0.20 | 6.0° | 7.0° | • |
| 7232946 | R6BPHP060H15R040 KCPM25S | 6 | 0.236 | 6.00 | 0.591 | 15 | 1.181 | 30 | 0.016 | 0.40 | 6.0° | 7.0° | • |
| 7232947 | R6BPHP060H22R020 KCPM25S | 6 | 0.236 | 6.00 | 0.866 | 22 | 1.457 | 37 | 0.008 | 0.20 | 6.0° | 7.0° | • |
| 7232948 | R6BPHP060H30R020 KCPM25S | 6 | 0.236 | 6.00 | 1.181 | 30 | 1.772 | 45 | 0.008 | 0.20 | 6.0° | 7.0° | • |
| 7232949 | R6BPHP060H30R040 KCPM25S | 6 | 0.236 | 6.00 | 1.181 | 30 | 1.772 | 45 | 0.016 | 0.40 | 6.0° | 7.0° | • |
| 7232950 | R6BPHP060H35R020 KCPM25S | 6 | 0.236 | 6.00 | 1.378 | 35 | 1.969 | 50 | 0.008 | 0.20 | 6.0° | 7.0° | • |
| 7232951 | R6BPHP060H42R020 KCPM25S | 6 | 0.236 | 6.00 | 1.653 | 42 | 2.244 | 57 | 0.008 | 0.20 | 6.0° | 7.0° | • |
| 7232952 | R6BPHP060H50R020 KCPM25S | 6 | 0.236 | 6.00 | 1.968 | 50 | 2.559 | 65 | 0.008 | 0.20 | 6.0° | 7.0° | • |
| 7232953 | R7BPHP070H25R020 KCPM25S | 7 | 0.276 | 7.00 | 0.984 | 25 | 1.575 | 40 | 0.008 | 0.20 | 6.0° | 7.0° | • |
| 7232954 | R7BPHP070H30R020 KCPM25S | 7 | 0.276 | 7.00 | 1.181 | 30 | 1.772 | 45 | 0.008 | 0.20 | 6.0° | 7.0° | • |
| 7232955 | R7BPHP070H30R040 KCPM25S | 7 | 0.276 | 7.00 | 1.181 | 30 | 1.772 | 45 | 0.016 | 0.40 | 6.0° | 7.0° | • |
| 7232956 | R7BPHP070H35R020 KCPM25S | 7 | 0.276 | 7.00 | 1.378 | 35 | 1.969 | 50 | 0.008 | 0.20 | 6.0° | 7.0° | • |
| 7232957 | R7BPHP070H40R020 KCPM25S | 7 | 0.276 | 7.00 | 1.575 | 40 | 2.165 | 55 | 0.008 | 0.20 | 6.0° | 7.0° | • |
| 7232958 | R7BPHP070H45R020 KCPM25S | 7 | 0.276 | 7.00 | 1.772 | 45 | 2.362 | 60 | 0.008 | 0.20 | 6.0° | 7.0° | • |
| 7232959 | R7BPHP070H50R020 KCPM25S | 7 | 0.276 | 7.00 | 1.969 | 50 | 2.559 | 65 | 0.008 | 0.20 | 6.0° | 7.0° | • |
