KenDrill HPR
B254 • 3xD • Внутреннее охлаждение • Прямая хвостовая часть (продолжение)
| Номер заказа | Номер каталога | D1 (мм) | D1 (дюйм) | L | L3 | L4 макс | L5 | LS | D | Марка |
|---|---|---|---|---|---|---|---|---|---|---|
| 6783054 | B254A10200HPR | 10,200 | .4016 | 102 | 55 | 40 | 2,6 | 45 | 12 | KCK10A |
| 6783055 | B254A10300HPR | 10,300 | .4055 | 102 | 55 | 40 | 2,6 | 45 | 12 | KCK10A |
| 6783056 | B254A10320HPR | 10,320 | .4063 | 102 | 55 | 40 | 2,6 | 45 | 12 | KCK10A |
| 6783057 | B254A10500HPR | 10,500 | .4134 | 102 | 55 | 40 | 2,6 | 45 | 12 | KCK10A |
| 6783058 | B254A10800HPR | 10,800 | .4252 | 102 | 55 | 40 | 2,7 | 45 | 12 | KCK10A |
| 6783059 | B254A11000HPR | 11,000 | .4331 | 102 | 55 | 40 | 2,8 | 45 | 12 | KCK10A |
| 6783060 | B254A11113HPR | 11,113 | .4375 | 102 | 55 | 40 | 2,8 | 45 | 12 | KCK10A |
| 6783071 | B254A11500HPR | 11,500 | .4528 | 102 | 55 | 40 | 2,9 | 45 | 12 | KCK10A |
| 6783072 | B254A11800HPR | 11,800 | .4646 | 102 | 55 | 40 | 3,0 | 45 | 12 | KCK10A |
| 6783073 | B254A12000HPR | 12,000 | .4724 | 102 | 55 | 40 | 3,0 | 45 | 12 | KCK10A |
| 6783074 | B254A12500HPR | 12,500 | .4921 | 107 | 60 | 43 | 3,1 | 45 | 14 | KCK10A |
| 6783075 | B254A12700HPR | 12,700 | .5000 | 107 | 60 | 43 | 3,2 | 45 | 14 | KCK10A |
| 6783076 | B254A13000HPR | 13,000 | .5118 | 107 | 60 | 43 | 3,3 | 45 | 14 | KCK10A |
| 6783077 | B254A13500HPR | 13,500 | .5315 | 107 | 60 | 43 | 3,4 | 45 | 14 | KCK10A |
| 6962053 | B254A13800HPR | 13,800 | .5433 | 107 | 60 | 43 | 3,5 | 45 | 14 | KCK10A |
| 6783078 | B254A14000HPR | 14,000 | .5512 | 107 | 60 | 43 | 3,5 | 45 | 14 | KCK10A |
| 6783079 | B254A14288HPR | 14,288 | .5625 | 115 | 65 | 45 | 3,6 | 48 | 16 | KCK10A |
| 6783080 | B254A14500HPR | 14,500 | .5709 | 115 | 65 | 45 | 3,6 | 48 | 16 | KCK10A |
| 6783081 | B254A15000HPR | 15,000 | .5906 | 115 | 65 | 45 | 3,8 | 48 | 16 | KCK10A |
| 6962054 | B254A15400HPR | 15,400 | .6063 | 115 | 65 | 45 | 3,9 | 48 | 16 | KCK10A |
| 6783082 | B254A15500HPR | 15,500 | .6102 | 115 | 65 | 45 | 3,9 | 48 | 16 | KCK10A |
| 6783083 | B254A16000HPR | 16,000 | .6299 | 115 | 65 | 45 | 4,0 | 48 | 16 | KCK10A |
| 6783084 | B254A16500HPR | 16,500 | .6496 | 123 | 73 | 51 | 4,1 | 48 | 18 | KCK10A |
| 6783085 | B254A17000HPR | 17,000 | .6693 | 123 | 73 | 51 | 4,3 | 48 | 18 | KCK10A |
| 6783086 | B254A17500HPR | 17,500 | .6890 | 123 | 73 | 51 | 4,4 | 48 | 18 | KCK10A |
| 6783087 | B254A18000HPR | 18,000 | .7087 | 123 | 73 | 51 | 4,5 | 48 | 18 | KCK10A |
| 6783088 | B254A18500HPR | 18,500 | .7283 | 131 | 79 | 55 | 4,6 | 50 | 20 | KCK10A |
| 6783089 | B254A19000HPR | 19,000 | .7480 | 131 | 79 | 55 | 4,8 | 50 | 20 | KCK10A |
| 6783090 | B254A20000HPR | 20,000 | .7874 | 131 | 79 | 55 | 5,0 | 50 | 20 | KCK10A |
KenDrill HPR
B255 • 5xD • Внутреннее охлаждение • Прямая хвостовая часть
| Номер заказа | Номер каталога | D1 (мм) | D1 (дюйм) | L | L3 | L4 макс | L5 | LS | D | Марка |
|---|---|---|---|---|---|---|---|---|---|---|
| 6783092 | B255A03000HPR | 3,000 | .1181 | 66 | 28 | 23 | 0,8 | 36 | 6 | KCK10A |
| 6783093 | B255A03048HPR | 3,048 | .1200 | 66 | 28 | 23 | 0,8 | 36 | 6 | KCK10A |
| 6783094 | B255A03100HPR | 3,100 | .1220 | 66 | 28 | 23 | 0,8 | 36 | 6 | KCK10A |
| 6783095 | B255A03175HPR | 3,175 | .1250 | 66 | 28 | 23 | 0,8 | 36 | 6 | KCK10A |
| 6783096 | B255A03200HPR | 3,200 | .1260 | 66 | 28 | 23 | 0,8 | 36 | 6 | KCK10A |
| 6783098 | B255A03300HPR | 3,300 | .1299 | 66 | 28 | 23 | 0,8 | 36 | 6 | KCK10A |
| 6783099 | B255A03400HPR | 3,400 | .1339 | 66 | 28 | 23 | 0,9 | 36 | 6 | KCK10A |
| 6783100 | B255A03455HPR | 3,455 | .1360 | 66 | 28 | 23 | 0,9 | 36 | 6 | KCK10A |
| 6783111 | B255A03500HPR | 3,500 | .1378 | 66 | 28 | 23 | 0,9 | 36 | 6 | KCK10A |
| 6783112 | B255A03571HPR | 3,571 | .1406 | 66 | 28 | 23 | 0,9 | 36 | 6 | KCK10A |
| 6783113 | B255A03600HPR | 3,600 | .1417 | 66 | 28 | 23 | 0,9 | 36 | 6 | KCK10A |
| 6783114 | B255A03700HPR | 3,700 | .1457 | 66 | 28 | 23 | 0,9 | 36 | 6 | KCK10A |
| 6783115 | B255A03800HPR | 3,800 | .1496 | 74 | 36 | 29 | 1,0 | 36 | 6 | KCK10A |
| 6783116 | B255A03900HPR | 3,900 | .1535 | 74 | 36 | 29 | 1,0 | 36 | 6 | KCK10A |
| 6783118 | B255A04000HPR | 4,000 | .1575 | 74 | 36 | 29 | 1,0 | 36 | 6 | KCK10A |
| 6783119 | B255A04039HPR | 4,039 | .1590 | 74 | 36 | 29 | 1,0 | 36 | 6 | KCK10A |
| 6783120 | B255A04100HPR | 4,100 | .1614 | 74 | 36 | 29 | 1,0 | 36 | 6 | KCK10A |
| 6783121 | B255A04200HPR | 4,200 | .1654 | 74 | 36 | 29 | 1,1 | 36 | 6 | KCK10A |
| 6783122 | B255A04300HPR | 4,300 | .1693 | 74 | 36 | 29 | 1,1 | 36 | 6 | KCK10A |
| 6783123 | B255A04400HPR | 4,400 | .1732 | 74 | 36 | 29 | 1,1 | 36 | 6 | KCK10A |
| 6783124 | B255A04500HPR | 4,500 | .1772 | 74 | 36 | 29 | 1,1 | 36 | 6 | KCK10A |
| 6783125 | B255A04600HPR | 4,600 | .1811 | 74 | 36 | 29 | 1,2 | 36 | 6 | KCK10A |
