Цельные твердосплавные микросверла линейки KenDrill Micro Kennametal 2025 - страница 10

P v M v K j N j v Primary S v 139° ± 1° j Secondary H KenDrill Micro 40xD • B075A KCU10 D1 Order Number Catalog Number mm in D L L3 L4 L5 LS 7071017 B075A01000 1.000 .0394 4 90 43.2 40.2 0.2 41 • 7071018 B075A01100 1.100 .0433 4 90 47.5 44.2 0.2 37 • 7071019 B075A01200 1.200 .0472 4 97 51.8 48.2 0.2 40 • 7071020 B075A01300 1.300 .0512 4 97 56.1 52.2 0.2 36 • 7071061 B075A01400 1.400 .0551 4 105 60.5 56.3 0.3 40 • 7071062 B075A01500 1.500 .0591 4 105 64.8 60.3 0.3 36 • 7071063 B075A01600 1.600 .0630 4 113 69.1 64.3 0.3 39 • 7071064 B075A01700 1.700 .0669 4 113 73.4 68.3 0.3 35 • 7071065 B075A01800 1.800 .0709 4 123 77.7 72.3 0.3 41 • 7071066 B075A01900 1.900 .0748 4 123 82.1 76.4 0.4 37 • 7071067 B075A02000 2.000 .0787 4 136 86.4 80.4 0.4 46 • 7071068 B075A02100 2.100 .0827 4 136 90.7 84.4 0.4 42 • 7071069 B075A02200 2.200 .0866 4 136 95.0 88.4 0.4 38 • 7071070 B075A02300 2.300 .0906 4 150 99.3 92.4 0.4 48 • 7071071 B075A02400 2.400 .0945 4 150 103.6 96.4 0.4 43 • 7071072 B075A02500 2.500 .0984 4 150 108.0 100.5 0.5 39 • 7071073 B075A02600 2.600 .1024 4 150 112.3 104.5 0.5 35 • 7071074 B075A02700 2.700 .1063 4 167 116.6 108.5 0.5 48 • 7071075 B075A02800 2.800 .1102 4 167 120.9 112.5 0.5 44 • 7071076 B075A02900 2.900 .1142 4 167 125.2 116.5 0.5 40 • P v M v K j N j v Primary S v 139° ± 1° j Secondary H KenDrill Micro 50xD • B076A KCU10 D1 Order Number Catalog Number mm in D L L3 L4 L5 LS 7071077 B076A01000 1.000 .0394 4 101.8 53.2 50.2 0.2 43 • 7223927 B076A01100 1.100 .0433 4 101.8 58.5 55.2 0.2 38 • 7223928 B076A01200 1.200 .0472 4 109.8 63.8 60.2 0.2 40 • 7223929 B076A01300 1.300 .0512 4 109.8 69.1 65.2 0.2 35 • 7223930 B076A01400 1.400 .0551 4 119.7 74.5 70.3 0.3 40 • 7071078 B076A01500 1.500 .0591 4 119.7 79.8 75.3 0.3 35 • 7223961 B076A01600 1.600 .0630 4 129.7 85.1 80.3 0.3 40 • 7223962 B076A01700 1.700 .0669 4 129.7 90.4 85.3 0.3 35 • 7223963 B076A01800 1.800 .0709 4 142.7 95.7 90.3 0.3 43 • 7223964 B076A01900 1.900 .0748 4 142.6 101.1 95.4 0.4 37 • 7071079 B076A02000 2.000 .0787 4 157.6 106.4 100.4 0.4 47 • 7223965 B076A02100 2.100 .0827 4 157.6 111.7 105.4 0.4 42 • 7223966 B076A02200 2.200 .0866 4 157.6 117.0 110.4 0.4 37 • 7223967 B076A02300 2.300 .0906 4 175.6 122.3 115.4 0.4 50 • 7223968 B076A02400 2.400 .0945 4 175.6 127.6 120.4 0.4 45 • 7071080 B076A02500 2.500 .0984 4 175.5 133.0 125.5 0.5 40 • 7223969 B076A02600 2.600 .1024 4 175.5 138.3 130.5 0.5 34 • 7223970 B076A02700 2.700 .1063 4 196.5 143.6 135.5 0.5 50 • 7223971 B076A02800 2.800 .1102 4 196.5 148.9 140.5 0.5 45 • 7223972 B076A02900 2.900 .1142 4 196.5 154.2 145.5 0.5 40 • 10
