| d2 3 | d2 4 | d2 6 | P | ROFESSIONA | Art.Nr. Art.No. L | 306212 62 | ||||||||
| Art. | d1 | r - 0,004 | l3 | d2 h5 | d3 | r2 | l1 | l2 | € | 0,5° | 1° | 2° | 3° | |
| 306212012001206 30 12 0 0 | I | 1,2 | 0,12 | 6 | 4 | 1,15 | 4 | 55 | 1,4 | 35,50 | 6,82 | 7,08 | 7,54 | 8,06 |
| 306212012001208 30 12 0 0 | I | 1,2 | 0,12 | 8 | 4 | 1,15 | 4 | 55 | 1,4 | 35,50 | 8,90 | 9,21 | 9,80 | 10,48 |
| 306212012001210 30 12 0 1 | I | 1,2 | 0,12 | 10 | 4 | 1,15 | 4 | 55 | 1,4 | 35,50 | 10,98 | 11,33 | 12,06 | 12,89 |
| 306212012001212 30 12 0 1 | I | 1,2 | 0,12 | 12 | 4 | 1,15 | 4 | 55 | 1,4 | 35,50 | 13,04 | 13,45 | 14,31 | 15,30 |
| 306212012001218 30 12 0 1 | I | 1,2 | 0,12 | 18 | 4 | 1,15 | 4 | 55 | 1,4 | 35,50 | 19,23 | 19,81 | 21,09 | 22,54 |
| 306212012001225 30 12 0 2 | % | 1,2 | 0,12 | 25 | 4 | 1,15 | 10 | 60 | 1,4 | 20,40 | 27,27 | 28,17 | 29,46 | – |
| 306212015001504 30 12 0 0 | I | 1,5 | 0,15 | 4 | 4 | 1,44 | 4 | 55 | 1,8 | 35,50 | 4,75 | 4,96 | 5,30 | 5,67 |
| 306212015001506 30 12 0 0 | I | 1,5 | 0,15 | 6 | 4 | 1,44 | 4 | 55 | 1,8 | 35,50 | 6,84 | 7,10 | 7,56 | 8,08 |
| 306212015001508 30 12 0 0 | I | 1,5 | 0,15 | 8 | 4 | 1,44 | 4 | 55 | 1,8 | 35,50 | 8,92 | 9,22 | 9,82 | 10,49 |
| 306212015001510 30 12 0 1 | I | 1,5 | 0,15 | 10 | 4 | 1,44 | 4 | 55 | 1,8 | 35,50 | 11,00 | 11,34 | 12,08 | 12,91 |
| 306212015001512 30 12 0 1 | I | 1,5 | 0,15 | 12 | 4 | 1,44 | 4 | 55 | 1,8 | 35,50 | 13,06 | 13,46 | 14,33 | 15,32 |
| 306212015001516 30 12 0 1 | I | 1,5 | 0,15 | 16 | 4 | 1,44 | 4 | 55 | 1,8 | 35,50 | 17,19 | 17,71 | 18,85 | 20,15 |
| 306212015001520 30 12 0 2 | I | 1,5 | 0,15 | 20 | 4 | 1,44 | 4 | 55 | 1,8 | 35,50 | 21,30 | 21,95 | 23,36 | – |
| 306212015003012 30 12 0 1 | % | 1,5 | 0,30 | 12 | 4 | 1,44 | 10 | 55 | 1,8 | 20,40 | 13,71 | 14,33 | 15,28 | 16,05 |
| 306212016001616 30 12 0 1 | % | 1,6 | 0,16 | 16 | 4 | 1,54 | 10 | 55 | 1,9 | 20,40 | 17,91 | 18,63 | 19,71 | 20,56 |
| 306212020002005 30 12 0 0 | I | 2,0 | 0,20 | 5 | 4 | 1,92 | 4 | 65 | 2,0 | 35,50 | 5,85 | 6,07 | 6,47 | 6,91 |
| 306212020002008 30 12 0 0 | I | 2,0 | 0,20 | 8 | 4 | 1,92 | 4 | 65 | 2,0 | 35,50 | 8,97 | 9,26 | 9,85 | 10,53 |
| 306212020002010 30 12 0 1 | I | 2,0 | 0,20 | 10 | 4 | 1,92 | 4 | 65 | 2,0 | 35,50 | 11,04 | 11,38 | 12,11 | 12,95 |
| 306212020002012 30 12 0 1 | I | 2,0 | 0,20 | 12 | 4 | 1,92 | 4 | 65 | 2,0 | 35,50 | 13,10 | 13,50 | 14,37 | 15,36 |
| 306212020002015 30 12 0 1 | I | 2,0 | 0,20 | 15 | 4 | 1,92 | 4 | 65 | 2,0 | 35,50 | 16,19 | 16,68 | 17,76 | 18,98 |
| 306212020002020 30 12 0 2 | I | 2,0 | 0,20 | 20 | 4 | 1,92 | 4 | 65 | 2,0 | 35,50 | 21,34 | 21,98 | 23,40 | – |
| 306212020002025 30 12 0 2 | I | 2,0 | 0,20 | 25 | 4 | 1,92 | 4 | 75 | 2,0 | 36,50 | 26,48 | 27,29 | – | – |
| 306212020002030 30 12 0 3 | I | 2,0 | 0,20 | 30 | 4 | 1,92 | 4 | 75 | 2,0 | 36,50 | 31,63 | 32,59 | – | – |
| 306212020005010 30 12 0 1 | I | 2,0 | 0,50 | 10 | 4 | 1,92 | 4 | 65 | 2,0 | 35,50 | 11,04 | 11,38 | 12,11 | 12,95 |
| 306212020005015 30 12 0 1 | I | 2,0 | 0,50 | 15 | 4 | 1,92 | 4 | 65 | 2,0 | 35,50 | 16,19 | 16,68 | 17,76 | 18,98 |
| 306212020005020 30 12 0 2 | I | 2,0 | 0,50 | 20 | 4 | 1,92 | 4 | 65 | 2,0 | 35,50 | 21,32 | 21,98 | 23,40 | – |
| 306212030003010 30 12 0 1 | I | 3,0 | 0,30 | 10 | 4 | 2,90 | 4 | 65 | 3,0 | 36,50 | 11,07 | 11,41 | 12,15 | – |
| 306212030003015 30 12 0 1 | I | 3,0 | 0,30 | 15 | 4 | 2,90 | 4 | 65 | 3,0 | 36,50 | 16,22 | 16,72 | – | – |
| 306212030003020 30 12 0 2 | I | 3,0 | 0,30 | 20 | 4 | 2,90 | 4 | 65 | 3,0 | 36,50 | 21,37 | 22,02 | – | – |
| 306212030003025 30 12 0 2 | I | 3,0 | 0,30 | 25 | 4 | 2,90 | 4 | 75 | 3,0 | 41,50 | 26,52 | 27,32 | – | – |
| 306212030003030 30 12 0 3 | I | 3,0 | 0,30 | 30 | 4 | 2,90 | 4 | 75 | 3,0 | 41,50 | 31,67 | – | – | – |
| 306212040003010 30 12 0 1 | I | 4,0 | 0,30 | 10 | 6 | 3,90 | 4 | 65 | 4,0 | 38,50 | 11,07 | 11,41 | 12,15 | 12,99 |
| 306212040003015 30 12 0 1 | I | 4,0 | 0,30 | 15 | 6 | 3,90 | 4 | 65 | 4,0 | 38,50 | 16,22 | 16,72 | 17,79 | 19,02 |
| 306212040003020 30 12 0 2 | I | 4,0 | 0,30 | 20 | 6 | 3,90 | 4 | 65 | 4,0 | 38,50 | 21,37 | 22,02 | 23,44 | – |
| 306212040003025 30 12 0 2 | I | 4,0 | 0,30 | 25 | 6 | 3,90 | 4 | 75 | 4,0 | 39,50 | 26,52 | 27,32 | – | – |
| 306212040003030 30 12 0 3 | I | 4,0 | 0,30 | 30 | 6 | 3,90 | 4 | 75 | 4,0 | 39,50 | 31,67 | 32,62 | – | – |
| 306212040005020 30 12 0 2 | I | 4,0 | 0,50 | 20 | 6 | 3,90 | 4 | 65 | 4,0 | 38,50 | 21,37 | 22,02 | 23,44 | – |
| 306212040005030 30 12 0 3 | I | 4,0 | 0,50 | 30 | 6 | 3,90 | 4 | 75 | 4,0 | 39,50 | 31,67 | 32,62 | – | – |
% Sonderpreis / Sale Artikel. Lieferbar solange Vorrat. Special price / sale article. While stocks last.
