Rd° HM90 EAL-HSK63A-15 D Shank Long Reach Endmills with Integral G2.5 HSK Adaptation Carrying HM90 AXCR ap Max. RPM 1505... Inserts for Machining Aluminum L1 U<1.0 gmm L7 L5 kg Designation D L 1 Z a p L 7 L 5 RPM max R d ° Shank HM90 EAL25-L50-HSK63A-15 25.00 45.0 2 15.00 50.00 76.00 37500 21.0 HSK A 63 0.747 SR 14-562 T-10/51 HM90 EAL25-L75-HSK63A-15 25.00 70.0 2 15.00 75.00 101.00 31250 21.0 HSK A 63 0.825 SR 14-562 T-10/51 HM90 EAL32-L65-HSK63A-15 32.00 60.0 3 15.00 65.00 91.00 31250 13.0 HSK A 63 0.897 SR 14-562 T-10/51 HM90 EAL32-L100-HSK63A-15 32.00 95.0 3 15.00 100.00 126.00 31250 13.0 HSK A 63 1.091 SR 14-562 T-10/51 HM90 EAL40-L80-HSK63A-15 40.00 75.0 3 15.00 80.00 106.00 26040 9.0 HSK A 63 1.189 SR 14-562 T-10/51 HM90 EAL40-L120-HSK63A-15 40.00 115.0 3 15.00 120.00 146.00 26040 9.0 HSK A 63 1.516 SR 14-562 T-10/51 • A cooling tube must be used with all internal coolant HSK spindles (should be ordered separately) • Insert tightening torque: 3.2 Nxm For inserts, see pages: HM90 AXCR 1505 (399) D3 Rd° Da HM90 FAL-15 CUTTERS FOR ALUMINUM Face Mills Carrying HM90 AXCR L 1505.. Inserts for Machining Aluminum ap D kg Designation D Z a p L D 3 Da Arbor (1) RPM max R d ° HM90 FAL-D050-4-22-15 50.00 4 13.50 45.00 49.00 22.00 A 23000 6.5 0.302 (1) For adaptation options, see page 461 For inserts, see pages: HM90 AXCR 1505 (399) For holders, see pages: BT-FC-SEM-C (906) • BT-SEM (905) • BT-SEM-C (906) • BT-SEMC (908) • C#-SEM (889) • C#-SEMC (890) • DIN2080-SEM (915) • DIN2080-SEMC (916) • DIN69871-SEM (854) • DIN69871-SEM-C (855) • DIN69871-SEMC (856) • HSK A-SEM (875) • HSK A-SEM-C (877) • HSK A-SEMC (876) • HSK E-SEM (874) • HSK FM-SEM (875) • SEM CF (CLICKFIT) (930) • SMH MB (757) Spare Parts Designation HM90 FAL-15 SR 14-562 BLD T10/S7 SW6-SD SR M10X25 DIN912 D3 Rd° Da HM90 FAL-22 Face Mills Carrying HM90 APCR L 2206... Inserts for Machining Aluminum ap D kg Designation D a p Z L D 3 Da Arbor (1) R d ° RPM max HM90 FAL-D050-22-22 50.00 20.50 2 55.00 49.00 22.00 A 10.0 21000 0.340 HM90 FAL-D063-27-22 63.00 20.50 3 50.00 62.00 27.00 A 7.0 16000 0.485 HM90 FAL-D080-27-22 80.00 20.50 3 50.00 70.00 27.00 A 5.0 14000 0.812 HM90 FAL-D100-32-22 100.00 20.50 4 50.00 81.26 32.00 B 4.0 13000 1.318 HM90 FAL-D125-40-22 125.00 20.50 5 50.00 85.26 40.00 B 3.0 11000 1.840 • D.O.C. changes according to insert radius • ap 20.5 is the value for HM90 APCR220650 • Insert tightening torque: 6 Nxm (1) For adaptation options, see page 461 For inserts, see pages: HM90 APCR 2206..R-P (401) • HM90 APCR 220605-CS (401) Spare Parts Designation HM90 FAL-D050-22-22 SR 14-0180 BLD T20/M7 SW6-T SR 105-1184 HW 8.0 HM90 FAL-D063-27-22 SR 14-0180 BLD T20/M7 SW6-T SR M12X25 HM90 FAL-D080-27-22 SR 14-0180 BLD T20/M7 SW6-T SR M12X25 HM90 FAL-D100-32-22 SR 14-0180 BLD T20/M7 SW6-T HM90 FAL-D125-40-22 SR 14-0180 BLD T20/M7 SW6-T 335
