| TGBHR/L-JHP | l2 h | h | |||||||||||
| Grooving and Turning SUMO-GRIP Tools with Channels for High Pressure Coolant | f T W | G 1/8"-28 l1 | b h4 typx2 | A | Rig | ht-han | d shown Bar Max | ||||||
| Designation | h | W | b | l2 | A | l1 | Tmax-r | f | h4 | ||||
| TGBHR/L 25-8-JHP | 25.0 | 8.00 | 25.0 | 42.0 | 7.00 | 150.00 | 25.00 | 21.5 | 12.0 | ETG 8-12 | PLG 1/8ISO1 | 179 | HW 5.0 |
| TGBHR/L 32-8-JHP | 32.0 | 8.00 | 32.0 | 42.0 | 7.00 | 170.00 | 25.00 | 28.5 | 12.0 | ETG 8-12 | PLG 1/8ISO1 | 179 | HW 5.0 |
- For user guide see pages 340-355
- Optional, should be ordered separately
For inserts, see pages: TAG N-C/W/M (399) TAGB/TAGBA (284)
Flow Rate vs. Pressure
70 Bar 100 Bar 140 Bar
Designation Flow Rate (liters/min) Flow Rate (liters/min) Flow Rate (liters/min)
TGBHR/L-JHP 13-16 19-21 22-24
ETG 8-12 Extractor for 8 to 12.7 mm Inserts Extraction Side
Insertion Side
| TGFH/R/L | TGFH...1 | .4/1.6 | Dmax TGFH...K | l1 | A 150º W h1 B1 | |||||
| Blades with a Tangentially Orient Pocket Carrying TANG-GRIP Sin Ended Inserts for Partingand Gr | ed gle- ooving | L3 | TGFH 100,150 | TGFH 100-9 | ||||||
| Designation | B1 | Wmin | Wmax | A | l1 | L3 h1 | Dmax | Insert | ||
| TGFH 52K-8(1) | 52.6 | 7.70 | 8.50 | 7.20 | 190.00 | - 45.2 | 190.0 | Y | TAG 8 | ETG 8-12 |
| TGFH 53K-8(1) | 52.6 | 7.70 | 8.50 | 7.20 | 260.00 | - 45.2 | 215.0 | Y | TAG 8 | ETG 8-12 |
| TGFH 52K-9(1) | 52.6 | 8.70 | 10.00 | 8.20 | 190.00 | - 45.2 | 190.0 | Y | TAG 9 | ETG 8-12 |
| TGFH 53K-9(1) | 52.6 | 8.70 | 10.00 | 8.20 | 260.00 | - 45.2 | 215.0 | Y | TAG 9 | ETG 8-12 |
| TGFHR/L 53K-12(1) | 52.6 | 11.70 | 12.70 | 10.00 | 260.00 | - 45.2 | 215.0 | Y | TAG 12 | ETG 8-12 |
| TGFH 100-9 | 100.0 | 8.70 | 10.00 | 8.20 | 460.00 | - 92.5 | 450.0 | N | TAG 9 | ETG 8-12 |
| TGFH 100-12 | 100.0 | 11.70 | 12.70 | 10.00 | 460.00 | - 92.5 | 450.0 | N | TAG 12 | ETG 8-12 |
| TGFH 150-12 | 150.0 | 11.70 | 12.70 | 10.00 | 610.00 | - 142.5 | 600.0 | N | TAG 12 | ETG 8-12 |
- For user guide, see pages 340-351
(1) With coolant holes, the recommended coolant pressure is 10 bar min.; cooling tube SGCU 341 should be ordered separately
- Optional, should be ordered separately
(2) Thickness beyond the D.O.C. area is 2.50 mm (3) Thickness beyond the D.O.C. area is 1.60 mm For inserts, see pages: TAG N-A (402) TAG N-C/W/M (399) TAG N-J/JS/JT (400) TAG N-LF (401) TAG N-MF (400) TAG N-UT (402) TAG R/L-C (399) TAG R/L-J/JS (401) TAGB/TAGBA (284) For holders, see pages: C#-TBK-R/L (477) HSK A-WH-TBK-R/L (482) SGTBF (473) SGTBK (473) SGTBR/L (473) SGTBU/SGTBN (472) UBHCR/L (473)
