ISOTURN INSERTS
S
91º 95º
TPGT-SP di
Super Positive Triangular Inserts l
with 11° Clearance for Fine d1
Boring and Finish Turning
r

Recommended
Dimensions Tough 1 Hard
Machining Data


IC908

IC907
ap f
Designation l di S r d1 (mm) (mm/rev)
TPGT 110202-SP 11.00 6.35 2.38 0.20 3.00 • • 0.40-1.00 0.05-0.15
• For user guide and cutting speed recommendations, see pages 197-212
For tools, see pages: E-STFPR/L-HEAD (97)


60°
91º 95º
TPMT
Triangular 11° Positive Inserts
l
with a Positive Chipformer
d1
Exerting Low Cutting Forces
11°
for Internal Finish Turning r
di S
Recommended
Dimensions Tough 1 Hard
Machining Data

IC520M
IC8350
IC8250
IC8150
IC50M
IC830
IC635


IC806
IC807
IC907
ap f
Designation l di S r d1 IC20 (mm)(1) (mm/rev)(1)
TPMT 110202 11.00 6.35 2.38 0.20 3.00 • • • 0.20-2.00 0.05-0.25
TPMT 110204 11.00 6.35 2.38 0.40 3.00 • • • • • • 1.00-3.00 0.12-0.30
TPMT 110208 11.00 6.35 2.38 0.80 3.00 • • • • 1.00-4.00 0.15-0.30
TPMT 160304 16.50 9.52 3.18 0.40 4.30 • • • • • • 1.00-4.00 0.12-0.30
TPMT 160308 16.50 9.52 3.18 0.80 4.30 • • • • • • • • • 5.00-12.00 0.15-0.35
• For cutting speed recommendations, see pages 197-212
(1) For turning
For tools, see pages: A/E/S-STFPR/L (97) • A/S-STLPR/L (98) • E-STFPR/L-HEAD (97)


91º 95º
TPMT-PF 11°
Triangular 11° Positive Inserts I
for Semi-Finishing and d1
Finishing Applications
r
S
di

Recommended
Dimensions Tough 1 Hard
Machining Data
IC8250

IC8150


ap f
Designation l di(1) S r d1 (mm) (mm/rev)
TPMT 110204-PF 11.00 6.35 2.38 0.40 3.00 • • 0.50-3.00 0.10-0.30
• For user guide and cutting speed recommendations, see pages 197-212
(1) Actual di=6.28, to be used in 6.35mm pocket size
For tools, see pages: A/E/S-STFPR/L (97) • A/S-STLPR/L (98) • E-STFPR/L-HEAD (97)


169
