FAST FEED MILLIG TOOLS OAL FFX4 ED LH Endmills Carrying Small DCX DC Rd° Double-Sided "Bone Shaped” DCONMS Inserts with 4 Cutting Edges for Fast Feed Milling APMX 17˚ Designation DCX(1) DC APMX AE(2) CICT(3) LH KAPR(4) OAL DCONMS RMPX°(5) MDN(6) MDX(7) Shank(8) Rg(9) MIID(10) TQ(11) kg FFX4 ED12-1-030-C12-04 12.00 4.60 0.80 3.7 1 30.0 17.0 90.00 12.00 3.6 16.60 23.00 C 1.80 FFX4 XNMU 040310T 0.9 0.07 FFX4 ED16-2-030-C16-04 16.00 8.60 0.80 3.7 2 30.0 17.0 120.00 16.00 4.3 24.60 31.00 C 1.80 FFX4 XNMU 040310T 0.9 0.16 FFX4 ED16-2-050-W20-04 16.00 8.60 0.80 3.7 2 50.0 17.0 110.00 20.00 4.3 24.60 31.00 W 1.80 FFX4 XNMU 040310T 0.9 0.20 FFX4 ED20-3-050-C20-04 20.00 12.60 0.80 3.7 3 50.0 17.0 140.00 20.00 2.7 32.60 39.00 C 1.80 FFX4 XNMU 040310T 0.9 0.29 FFX4 ED20-3-060-W20-04 20.00 12.60 0.80 3.7 3 60.0 17.0 120.00 20.00 2.7 32.60 39.00 W 1.80 FFX4 XNMU 040310T 0.9 0.24 FFX4 ED25-4-060-C25-04 25.00 17.60 0.80 3.7 4 60.0 17.0 150.00 25.00 1.8 42.60 49.00 C 1.80 FFX4 XNMU 040310T 0.9 0.50 FFX4 ED25-4-080-W25-04 25.00 17.60 0.80 3.7 4 80.0 17.0 140.00 25.00 1.8 42.60 49.00 W 1.80 FFX4 XNMU 040310T 0.9 0.45 FFX4 ED32-5-080-W32-04 32.00 24.60 0.80 3.7 5 80.0 17.0 150.00 32.00 1.2 56.60 63.00 W 1.80 FFX4 XNMU 040310T 0.9 0.80 FFX4 ED32-5-120-C32-04 32.00 24.60 0.80 3.7 5 120.0 17.0 205.00 32.00 1.2 56.60 63.00 C 1.80 FFX4 XNMU 040310T 0.9 1.02 • To generate a straight surface without cusps, the width of cut must not exceed DC (1) Cutting diameter maximum (2) Maximum plunging width (3) Number of inserts (4) Tool cutting edge angle (5) Maximum ramping angle (6) Machinable diameter minimum for interpolation (7) Machinable diameter maximum for interpolation (8) C-Cylindrical, W-Weldon (9) Radius for programming (10) Master insert identification (11) Recommended tightening torque (N*m) for insert screw For inserts, see pages: FFX4 XNMU-04 (523) Spare Parts Designation FFX4 ED SR M2.5X6-T7-60 T-7/51 OAL LF Rd° FFX4 ED-M DCX DC THSZMS DCONMS Endmills with FLEXFIT Adaptation Carrying Small "Bone Shaped” Inserts with 4 Cutting Edges APMX 17˚ DRVS for Fast Feed Milling Designation DCX(1) DC CICT(2) APMX AE(3) THSZMS LF OAL DCONMS RMPX°(4) MDN(5) MDX(6) DRVS(7) Rg(8) MIID(9) TQ(10) TQ_3(11) kg FFX4 ED20/.78-3-M10-04 20.00 12.60 3 0.80 3.7 M10 25.00 45.00 18.00 2.7 32.60 39.00 15.0 1.80 FFX4 XNMU 040310T 0.9 29 0.04 FFX4 ED25/.98-4-M12-04 25.00 17.60 4 0.80 3.7 M12 30.00 52.00 21.00 1.8 42.60 49.00 19.0 1.80 FFX4 XNMU 040310T 0.9 33 0.08 FFX4 ED32/1.26-5-M16-04 32.00 24.60 5 0.80 3.7 M16 35.00 60.00 29.00 1.2 56.60 63.00 27.0 1.80 FFX4 XNMU 040310T 0.9 40 0.18 FFX4 ED35/1.38-5-M16-04 35.00 27.60 5 0.80 3.7 M16 35.00 60.00 29.00 1.1 62.60 69.00 25.0 1.80 FFX4 XNMU 040310T 0.9 40 0.20 FFX4 ED42/1.65-6-M16-04 42.00 34.60 6 0.80 3.7 M16 40.00 65.00 29.00 0.8 76.60 83.00 25.0 1.80 FFX4 XNMU 040310T 0.9 40 0.30 • To generate a straight surface without cusps, the width of cut must not exceed DC • When mounting items with FLEXFIT threaded adaptation to their holders, the mating surfaces and threaded areas must be thoroughly cleaned. Apply appropriate tightening torque to eliminate a gap between the mating faces. Estimated torque values are specified in the TQ_3 parameter (1) Cutting diameter maximum (2) Number of inserts (3) Maximum plunging width (4) Maximum ramping angle (5) Machinable diameter minimum for interpolation (6) Machinable diameter maximum for interpolation (7) Torque key size (8) Radius for programming (9) Master insert identification (10) Recommended tightening torque (N*m) for insert screw (11) Tool tightening torque Nxm (lbfxin) For inserts, see pages: FFX4 XNMU-04 (523) For holders, see pages: BT-ODP (FLEXFIT) (314) • C#-ODP (FLEXFIT) (314) • CAB M-M (FLEXFIT) (312) • DIN69871-ODP (315) • ER-ODP (315) • HSK A-ODP (FLEXFIT) (316) • S M (312) • S M-C-H (312) • S M-CF (313) Spare Parts Designation FFX4 ED-M SR M2.5X6-T7-60 T-7/51 294 ISCAR
