Boring Head Peripheral Cartridge

Universal Marking for Deep Drilling Tools

CA - P - DR - 0800 - R

PeripheralDR : DrillingICL/R
Spare PartsCartridgeCB : Counter BoreHAND
DesignationAdjustment ScrewKeyLocking ScrewKeyInsert Clamping Screw Insert
CAOD-080SR 11201755-4HW 1.5SR 11201756-11HW 2.0NPMX 0803..R-GSR 11201753-2
CAOD-0845SR 11201755-6HW 2.0SR 11201756-10HW 2.5TPMX 1403..R-GSR 11201753-3
CAOD-085SR 11201755-7HW 1.5SR 11201756-11HW 2.0NPMX 0803..R-GSR 11201753-2
CAOD-103SR 11201755-8HW 2.5SR 11201756-12HW 3.0TPMX 1704..R-GSR 11201753-7
CAOD-142SR 11201755-9HW 2.5SR 11201756-15HW 4.0TPMX 2405..R-GSR 11201753-9
CAOD-170SR 11201755-11HW 3.0SR 11201756-15HW 4.0TPMX 2807..R-GSR 11201753-10

CAID

Drilling Head Inner Cartridge

Universal Marking for Deep DrillingTools
CA- I - 0845 - R
Spare PartsInter Cartnal ridge IC L/R HAND
DesignationLockingScrewKeyInsertInsert ClampingScrewKey
CAID-080SR 11201753-5T-9/51NPMX 0803..R-GSR 11201753-2T-7/51
CAID-0845SR 11201753-6T-15/51TPMX 1403..R-GSR 11201753-3T-8/51
CAID-085SR 11201753-5T-9/51NPMX 0803..R-GSR 11201753-2T-7/51
CAID-103SR 11201752-1T-15/51TPMX 1704..R-GSR 11201753-7T-9/51
CAID-142SR 11201756-7HW 3.0TPMX 2405..R-GSR 11201753-9T-15/51
CAID-170SR 11201756-7HW 3.0TPMX 2807..R-GSR 11201753-10T-20/51

SGP

Drilling Head Sub-Guide Pads b

OAL H

DesignationOALbH
SGP-0110.006.03.0
SGP-0210.008.04.5
SGP-0310.0010.05.0
SGP-0420.0014.07.0
