ITS BORE OAH ADJRGR BHD 50 L200 DCN-DCX Digital Fine Boring Slide Head for TCH AL Large Diameter Holders OAL IHFF 50 IHRF 50 CH45 54-800 IHRF 50 IHRF 50 CH30 54-800 Serrated Surface IHRF 56-802BW IHRF 50 CH15 54-800 kg Designation DCN(1) DCX(2) OAL OAH ADJRGR RPMX(3) BHD 50 L200 200.0 1202.0 110.00 74.0 5.00 20000 1.70 (1) Cutting diameter minimum (2) Cutting diameter maximum (3) Maximum RPM For tools, see pages: IHFF (436) • IHRF (436) • IHRF-BW (439) • IHRF-CH (439) ADJRGR LF (assembly) BHF L200 Fine Boring Slide Head for TCH DCN-DCX AL Large Diameter Holders OAL IHFF50 IHRF 50 CH45 54-800 Serrated Surface IHRF 50 IHRF 50 CH30 54-800 IHRF 56-802BW IHRF 50 CH15 54-800 kg Designation DCN(1) DCX(2) OAL LF ADJRGR BHF L200 200.0 1202.0 110.00 67.0 5.00 1.27 (1) Cutting diameter minimum (2) Cutting diameter maximum For tools, see pages: IHFF (436) • IHRF (436) • IHRF-BW (439) • IHRF-CH (439) 0 2 4 6 8 10 CW200 Counter Balancing Weight OAL for TCH AL Rough and Fine Boring Holders 30x56.5 kg Designation OAL CW200 105.00 1.12 437
