EXCHANGEABLE HEADS HOLDERS CDX LPR C#-HADHolders with CAMFIX DCONMS Exchangeable Tapered Shanks for Internal Facing Adapters WF 26 CDX - See specific adapter dimensions Designation DCONMS LPR WF CDI(1) C4 HAD 40.00 60.00 18.0 1 SR 14-519 T-20/3 SR M4X6DIN912 HW 3.0 C5 HAD 50.00 60.00 18.0 1 SR 14-519 T-20/3 SR M4X6DIN912 HW 3.0 C6 HAD 63.00 60.00 22.0 1 SR 14-519 T-20/3 SR M4X6DIN912 HW 3.0 (1) 1 - Hole for data chip, 0 - Without hole for data chip For tools, see pages: HFAER/L-4 (565) • HFAER/L-5T, 6T (566) • HFAIR/L-4 (572) • HFAIR/L-DG (573) • HGAER/L-3 (565) • HGAIR/L-3 (568) C#-HAPR/L 8 DCONMS Perpendicular Holders with CAMFIX Exchangeable Shanks for Internal Facing Adapters LF CDX Right-hand shown • CDX - See specific adapter dimensions Designation DCONMS LF CDI(1) C4 HAPR/L 40.00 50.00 1 SR 14-519 T-20/3 C6 HAPR/L 63.00 50.00 1 SR 14-519 T-20/3 (1) 1 - Hole for data chip, 0 - Without hole for data chip For tools, see pages: HFAER/L-4 (565) • HFAER/L-5T, 6T (566) • HFAIR/L-4 (572) • HFAIR/L-DG (573) • HGAER/L-3 (565) • HGAIR/L-3 (568) LPR BD C#-HATA CAMFIX Toolholder with a DCONMS Serrated Connection Adaptation Designation DCONMS BD LPR CDI(1) C6 HATA 63.00 106.00 66.00 1 (1) 1 - Hole for data chip, 0 - Without hole for data chip Spare Parts Designation C6 HATA SR M8X45 DIN 913 SR M8X25 DIN913 HW 4.0 SR M6X6 DIN913 TL360 HW 3.0 BH NUT BHR MB80 SR M12X35DIN912 HW 10.0 627
