IC08 GROOVE-TURN LH HH CNT PCHR/L-27-JHP-MC Bar Max Tools Carrying Pentagonal HF H Coolant Outlets Wide Inserts for Specially HBH Tailored Profiles HBL OAL HBKW CW B Right-hand shown Designation CW H HF B HBKW OAL LH HBH HBL CNT HH PCHR/L 20-27-10-JHP-MC 10.00 20.0 20.0 20.0 5.00 102.00 32.0 13.0 33.0 G1/8x9 17.4 PCHR/L 25-27-10-JHP-MC 10.00 25.0 25.0 25.0 - 117.00 32.0 8.0 33.0 G1/8x9 17.4 PCHR/L 20-27-15-JHP-MC 15.00 20.0 20.0 20.0 5.00 102.00 32.0 13.0 33.0 G1/8x9 17.4 PCHR/L 25-27-15-JHP-MC 15.00 25.0 25.0 25.0 - 117.00 32.0 8.0 33.0 G1/8x9 17.4 PCHR/L 20-27-20-JHP-MC 20.00 20.0 20.0 20.0 5.00 102.00 32.0 13.0 33.0 G1/8x9 17.4 PCHR/L 25-27-20-JHP-MC 20.00 25.0 25.0 25.0 - 117.00 32.0 8.0 33.0 G1/8x9 17.4 For inserts, see pages: PENTAS 27 blanks (323) Spare Parts Designation PCHR/L 20-27-20-JHP-MC SR M3X6 ISO7380 SS HW 3.0 SR M6X6 DIN913 SR M6X6 DIN913 TL360 PUSH ROD - 40529 HW 4.0 PLG G1/8 TL360 HW 5.0 PCHL 25-27-20-JHP-MC SR M3X6 ISO7380 SS HW 3.0 SR M6X6 DIN913 SR M6X6 DIN913 TL360 PUSH ROD - 40529 HW 4.0 PLG G1/8 TL360 HW 5.0 PCHR 25-27-20-JHP-MC PUSH ROD - 40529 HW 4.0 PENTAS 27 blanks CDX ø27 BW Blank Inserts with 5 Wide Cutting Edges for the Production of Special Profile Contours CW Dimensions Designation CW CDX BW PENTAS 27-10FT 10.00 4.00 11.80 • PENTAS 27-15FT 15.00 4.00 16.80 • PENTAS 27-20FT 20.00 4.00 21.80 • For tools, see pages: PCHR/L-27-JHP-MC (314) 335
