GROOVE-TURN LH TGBHR/L-JHP HF H Grooving and Turning HBH SUMO-GRIP Tools with Channels G 1/8"-28 typx2 WB for High-Pressure Coolant OAL Bar Max CDX WF B CW Right-hand shown Designation H CW HF B LH WB OAL CDX(1) WF HBH TGBHR/L 25-8-JHP 25.0 8.00 25.0 25.0 42.0 7.00 150.00 25.00 21.50 12.0 TGBHR/L 32-8-JHP 32.0 8.00 32.0 32.0 42.0 7.00 170.00 25.00 28.50 12.0 • For user guide see pages 419-436 (1) Cutting depth maximum For inserts, see pages: TAG N-C/W/M (506) • TAGB/TAGBA (333) Flow Rate vs. Pressure 70 Bar 100 Bar 140 Bar Designation Flow Rate (liters/min) Flow Rate (liters/min) Flow Rate (liters/min) TGBHR/L-JHP 13-16 19-21 22-24 ETG 8-12 Extractor for 8 to 12.7 mm Inserts Extraction Side Insertion Side Spare Parts Designation TGBHL 25-8-JHP ETG 8-12 TGBHR/L 25-8-JHP PLG 1/8ISO1179 HW 5.0 TGBHR 25-8-JHP ETG 8-12* TGBHL 32-8-JHP PLG 1/8ISO1179 HW 5.0 TGBHR 32-8-JHP ETG 8-12* PLG 1/8ISO1179 HW 5.0 * Optional, should be ordered separately 331
