CUT-GRIP CUT-GRIP
| Recommended Torque Range | Adjustabl Torque | e | Recommended Torque Range | Adjustabl Torque | e | ||
| Tool | [Nm] | Handle | Key Blade | Tool | [Nm] | Handle | Key Blade |
| GHDR/L (short pock | et) | GHDR/L/N 12/14 | |||||
| GHDR/L 12-3 | 4-5 | BLD 6 T20 | GHDR/L 2525-14T12 | 16-17 | |||
| GHDR/L 16-3 | 5-6 | BLD 6 HEX4 | GHDR/L 32-12 | 15-16 | |||
| GHDR/L 16-3 ST | 5-6 | BLD 6 HEX4 | GHDR/L 3232-14T12 | 16-17 | |||
| GHDR/L 16-4 | 7-8 | BLD 6 HEX5 | GHDR/L 3232-14T38 | 18-20 | Not Available | Not Available | |
| GHDR/L 16-4 ST | 7-8 | BLD 6 HEX5 | GHDN 3232-14T38 | 18-20 | |||
| GHDR/L 20-3 | 5-6 | BLD 6 HEX4 | GHDR/L 4040-14T38 | 18-20 | |||
| GHDR/L 20-4 | 7-8 | BLD 6 HEX5 | GHDN 4040-14T38 | 18-20 | |||
| GHDR/L 20-5 | 8-9 | BLD 6 HEX5 | GHGR/L | ||||
| GHDR/L 25-3 | 5-6 | TSA 6 5-14 | BLD 6 HEX4 | GHGR/L 16-3 | 7-8 | BLD 6 HEX5 | |
| GHDR/L 25-4 | 7-8 | BLD 6 HEX5 | GHGR/L 16-3 ST | 7-8 | TSA 6 5-1 | 4 BLD 6 HEX5 | |
| GHDR/L 25-5 | 8-9 | BLD 6 HEX5 | GHGR 16-4 | 7-8 | BLD 6 HEX5 | ||
| GHDR/L 25-6 | 9-10 | BLD 6 HEX5 | GHGR/L 20-2 | 4-6 | HSA 4 1-5 | BLD 4 HEX4 | |
| GHDR/L 32-3 | 6-7 | BLD 6 HEX4 | GHGR/L 20-3 | 7-8 | TSA 6 51 | BLD 6 HEX5 | |
| GHDR/L 32-4 | 8-10 | BLD 6 HEX5 | GHGR/L 20-4 | 7-8 | - | BLD 6 HEX5 | |
| GHDR/L 32-5 | 9-11 | BLD 6 HEX5 | GHGR/L 25-2 | 4-5 | HSA 4 1-5 | BLD 4 HEX4 | |
| GHDR/L 25-P8 | 13-14 | BLD 6 HEX6 | GHGR/L 25-3 | 6-8 | BLD 6 HEX5 | ||
| GHDR/L 32-P8 | 10-12 | BLD 6 HEX6 | GHGR/L 25-4 | 8-10 | BLD 6 HEX5 | ||
| GHDR/L-JHP (short | pocket) | GHGR/L 25-425 | 8-10 | BLD 6 HEX5 | |||
| GHDR/L 20-3-JHP | 5-6 | BLD 6 HEX4 | GHGR/L 25-5 | 9-11 | TSA 6 5-1 | 4 BLD 6 HEX5 | |
| GHDR/L 20-4-JHP | 7-8 | BLD 6 HEX5 | GHGR/L 25-630 | 10-12 | BLD 6 HEX5 | ||
| GHDR/L 25-3-JHP | 7-8 | SA 6 51 | BLD 6 HEX4 | GHGR/L 32-5 | 10-12 | BLD 6 HEX5 | |
| GHDR/L 25-4-JHP | 10-11 | - | BLD 6 HEX5 | GHGR/L 32-632 | 10-12 | BLD 6 HEX5 | |
| GHDR/L 25-5-JHP | 10-12 | BLD 6 HEX5 | GHMR/L | ||||
| GHDR/L 25-P8-JHP | 10-11 | BLD 6 HEX5 | GHMR/L 12 | 8-9 | BLD 6 T20 | ||
| GHDR/L-JHP (long p | ocket) | GHMR/L 16 | 10-12 | BLD 6 HEX5 | |||
| GHDR/L 32-8-JHP | 15-17 | Not | Not | GHMR/L 16-3 ST | 10-12 | BLD 6 HEX5 | |
| Available | Available | GHMR/L 20 | 10-12 | TSA 6 5-1 | BLD 6 HEX5 | ||
| GHDR/L-8A | GHMR/L 25 | 10-12 | BLD 6 HEX5 | ||||
| GHDR/L 25-8A | 10-12 | TSA 6 5-1 | BLD 6 HEX5 | GHMR/L 32 | 10-12 | BLD 6 HEX5 | |
| GHDR/L 32-8A | 10-12 | BLD 6 HEX5 | GHMPR/L | ||||
| GHDR/L (long pocke | t) | GHMPR/L 16 | 4-5 | BLD 6 HEX5 | |||
| GHDR/L 25-8 | 10-12 | BLD 6 HEX5 | GHMPR/L 20 | 5-6 | TSA 6 5-1 | 4 BLD 6 HEX5 | |
| GHDR/L 25-812 | 10-12 | BLD 6 HEX5 | GHMPR/L 25 | 8-9 | BLD 6 HEX5 | ||
| GHDR/L 32-8 | 10-12 | TSA 6 5-14 | BLD 6 HEX5 | GHMUR/L | |||
| GHDR/L 3225-8 | 10-12 | BLD 6 HEX5 | GHMUR/L 16 | 6-7 | BLD 6 HEX5 | ||
| GHDR/L 32-812 | 11-12 | BLD 6 HEX5 | GHMUR/L 20 | 8-10 | TSA 6 5-1 | 4 BLD 6 HEX5 | |
| GHDR/L 25-10 | 15-17 | GHMUR/L 25 | 10-11 | BLD 6 HEX5 | |||
| GHDR/L 32-836 | 16-17 | Not | Not | GHSR/L | |||
| GHDR/L 32-10 | 15-17 | Available | Available | GHSR/L 10-2 | 2-3 | BLD 4 T15 | |
| GHDR/L 40-10 | 16-17 | GHSR/L 12-2 | 2-3 | HSA 4 1-5 | BLD 4 T15 | ||
| C#-GHDR/L | GHSR/L 14-2 | 2-3 | BLD 4 T15 | ||||
| C4 GHDR/L-3 | 6-7 | BLD 6 HEX4 | GHSR/L 16-2 | 4-5 | TSA 6 5-1 | 4 BLD 6 T20 | |
| C4 GHDR/L-4 | 7-8 | BLD 6 HEX5 | CGHN-P8 | ||||
| C5 GHDR/L-3 | 6-7 | BLD 6 HEX4 | CGHN 52-P8 | 6-7 | BLD 6 HEX4 | ||
| C5 GHDR/L-4 | 7-8 | BLD 6 HEX5 | CGHN 53-P8 | 6-7 | TSA 6 5-1 | 4 BLD 6 HEX4 | |
| C5 GHDR/L-5 | 8-9 | TSA 6 5-14 | BLD 6 HEX5 | CGHN-8-10D | |||
| C6 GHDR/L-3 | 6-7 | BLD 6 HEX4 | CGHN 52-8D | 7-8 | BLD 6 HEX4 | ||
| C6 GHDR/L-4 | 7-8 | BLD 6 HEX5 | CGHN 53-8D | 7-8 | BLD 6 HEX4 | ||
| C6 GHDR/L-5 | 8-9 | BLD 6 HEX5 | CGHN 52-10D | 9-11 | TSA 6 5-1 | BLD 6 HEX5 | |
| C6 GHDR/L-8 | 10-12 | BLD 6 HEX5 | CGHN 53-10D | 9-11 | BLD 6 HEX5 | ||
| CGHR/L-12-14D | |||||||
| CGHR/L 53-12D | 10-12 | BLD 6 HEX5 | |||||
| CGHR/L 53-14D | 10-12 | TSA 6 5-1 | 4 BLD 6 HEX5 |
