IC902IC908IC908 THREAD MILLING TOOLS OAL MTECI-ISO LU Small Diameter Single Point Internal ISO Profile Solid DC DCONMS Carbide Thread Mills 60° Application: General engineering TP NUT Dimensions TP/4 60˚ TP/8 SCREW Designation TP(1) M Coarse M Fine DCONMS DC NOF(2) LU OAL Shank(3) MTECI 03009C4 0.25ISO 0.250 M1.2X0.25 M1.4X0.25, M1.6X0.25 3.00 0.90 3 4.3 39.00 C • MTECI 03007C3 0.25ISO 0.250 M1X0.25 - 3.00 0.72 3 3.6 39.00 C • MTECI 03011C5 0.3ISO 0.300 M1.4X0.3 - 3.00 1.05 3 5.0 39.00 C • MTECI 03012C6 0.35ISO 0.350 M1.6X0.35 M2X0.35, M2.2X0.35 3.00 1.20 3 5.7 39.00 C • MTECI 03016C7 0.4ISO 0.400 M2X0.4 - 3.00 1.55 3 7.1 39.00 C • MTECI 03024C10 0.5ISO 0.500 M3X0.5 M3.5X0.5, M4X0.5 3.00 2.37 3 10.6 39.00 C • • For user guide, see pages 435-442 (1) Thread pitch (2) Number of flutes (3) C-Cylindrical RE THFT D1 SD TRD-M-SP DC DCONMS Interchangeable Solid Carbide Heads for 60° Partial Profile Thread Milling PDX CDXOAL NUT Dimensions 60° SCREW Designation DC DMIN DIOUT(1) THFT(2) TPN(3) TPX(4) TPIN(5) TPIX(6) PDX RE D1 CDX OAL ZEFP(7) DCONMS SD TRD32-M60-6P-SP15 31.70 42.00 36.00 VP60 4.000 6.000 4.00 6.00 3.70 0.30 8.40 4.70 7.70 8 15.00 • SD TRD40-M60-8P-SP17 39.70 57.00 64.00 VP60 6.000 8.000 3.00 4.00 4.50 0.40 9.80 6.20 9.50 10 17.00 • • For shanks, see pages 329-331 • For user guide, see pages 435-442 (1) Minimum diameter for external threading (2) VP60=60° partial thread form (3) Thread pitch minimum (mm) (4) Thread pitch maximum (mm) (5) Threads per inch minimum (6) Threads per inch maximum (7) Num. of cutting edges RE THFT D1 SD TRD-W-SP DC DCONMS Interchangeable Solid Carbide Heads for 55° Partial Profile Thread Milling PDX CDXOAL NUT60° Dimensions SCREW Designation DC DMIN DIOUT(1) THFT(2) THFT_2 TPIN(3) TPIX(4) PDX D1 CDX OAL ZEFP(5) RE DCONMS SD TRD32-W55-4T-SP15 31.70 46.00 35.00 VP55 WH55 4.00 6.00 3.70 8.40 4.70 7.70 8 0.50 15.00 • SD TRD40-W55-3T-SP17 39.70 57.00 57.00 VP55 WH55 3.00 4.00 4.50 9.80 6.20 9.50 10 0.80 17.00 • • For shanks, see pages 329-331 • For user guide, see pages .. (1) Minimum diameter for external threading (2) VP55=55° partial thread forms (3) Threads per inch minimum (4) Threads per inch maximum (5) Num. of cutting edges 409
