MILLING INSERTS IC330 IC328IC830 IC808 IC908 IC810 IC07 W1 L PLHT Tangentially Clamped Inserts with 4 Cutting Edges for Plungers S 3.94 Dimensions Tough 1  Hard RecommendedMachining Data fz Designation W1 L S (mm/t) PLHT 1305-PDX 5.45 13.70 9.95 • • 0.12-0.12 • For cutting speed recommendations, see pages 542-547 HTP LN.. 0604 W1 S Tangentially Clamped Inserts with 4 Cutting Edges for Plungers L RE Dimensions Tough 1  Hard RecommendedMachining Data fz Designation W1 L S RE (mm/t) HTP LNAR 0604 FR-P 4.06 6.50 6.77 0.80 • 0.05-0.15 HTP LNHT 0604 ER 4.06 6.50 6.77 1.00 • • • • 0.08-0.12 HTP LNHT 0604 ETR 4.06 6.50 6.77 1.00 • • • 0.08-0.12 HTP LNMT 0604 ER (1) 4.06 6.50 6.84 0.60 • • 0.08-0.15 • FR-P-For machining aluminum, ER- For general applications, ETR- First priority for hardened steel • For cutting speed recommendations, see pages 542-547 (1) Mounting this insert increases tool diameter by 0.2 mm For tools, see pages: HTP-LN06 (252) • HTP-M-LN06 (252) ER ETR ER- For general ETR- First priority applications for hardened steel 536 ISCAR
