THREADING USER GUIDE Special Request Form Thread Turning Project Customer Industry Country Information Customer Goal (Productivity, Economy, etc.): Proposal for: o Finish Insert o Rough Insert o Holder o Machining Concept ISCAR Representative: Email: Tel: Competitors: Target Price: Annual Consumption: Threading Designation Pitch Standard Tolerance Clas Major Dia. Minor Dia. Pitch Dia. Number of Starts Threading Depth o Through Hole o Blind Hole Special Form For non-standard profiles, detailed information must be supplied (drawing, dimensions & tolerances) Application Part Material Hardness LH LH RH RH Right-hand Threading o RH o o o LH LH LH RH Left-hand Threading o o RH o o Insert Profile: o Full o Partial o Semi-Partial o Multi-Point 1-3° 1 2 3 4 5 Infeed: o Radial o Incremental o Flank o Modified Flank Attachments o Drawing o Model o Sketch o Photo Machine Model Shank Type/Size Coolant: o Internal o External o None Type: Remarks: 728 ISCAR
