.510 .510 .510
.510 R.031 .200 .510 R.031 .200 .510 R.060 .200
| SDES130515N-001 | SDES130532R | SDES130532R-001 | |||
| R.125 | R.125 | ||||
| .510 | |||||
| .512 | .512 |
.510 R.060 .200 .512 .200 .512 .200
| SDMS130508R-PH | SDMS130515R-PH | SDMS130608N-FL | |||
| .512 | .512 | ||||
| R.031 |
.512 R.031 .200 .512 R.060 .200 .532 .239
| SDMS130615N-FL | ZDES130515R | ZDES130515R-001 | ||
| .510 | .510 |
| .523 | R.060 | .239 | R.060 | .200 | .510 | R.060 | .200 | ||
| .510 | |||||||||
| ZDMS130515R-PH | |||||||||
| .512 | |||||||||
| .512 | R.060 | .200 |
Part Number Application Station ades IN2505 IN2530 IN4005 IN4015 IN4030 IN4035
| SDES130508N | Flat Top - Landed Edge - 0.031“ R | End & Side |
| SDES130508N-001 | Flat Top - Keen Edge - 0.031“ R | End & Side |
| SDMS130508R-PH | Positive Geometry - 0.031“ R | End & Side |
| SDMS130608N-FL | Positive Geometry - 0.031“ R | End: True 90 |
| SDES130515N | Flat Top - Landed Edge - 0.060“ R | End & Side |
| SDES130515N-001 | Flat Top - Keen Edge - 0.060“ R | End & Side |
| SDMS130515R-PH | Positive Geometry - 0.060“ R | End & Side |
| SDMS130615N-FL | Positive Geometry - 0.060“ R | End: True 90 |
| SDES130532R | Flat Top - Landed Edge - 0.125“ R | End |
| SDES130532R-001 | Flat Top - Keen Edge - 0.125“ R | End |
| ZDES130515R | Flat Top - Splitters - Landed Edge - 0.060“ R | End & Side |
| ZDES130515R-001 | Flat Top - Splitters - Keen Edge - 0.060“ R | End & Side |
| ZDMS130515R-PH | Positive - Splitters - 0.060“ R | End & Side |
| HARDWARE |
| Screw Retention Bolt | Driver Handle | Screw Driver Blade | Driver Bit (Optional) | Torque Driver Handle (Optional) | ||
| 25J3P-20023D1R01 | SM40-100-R0 | SD-06-50 | DS-A00T | DS-T156B | DS-T15B1 | DT-35-02 |
| 25J3P-20023D1R02 | SM40-100-R0 | SD-06-50 | DS-A00T | DS-T156B | DS-T15B1 | DT-35-02 |
| 25J3P-20030D1R01 | SM40-100-R0 | SD-06-79 | DS-A00T | DS-T156B | DS-T15B1 | DT-35-02 |
| 25J3P-20030D1R02 | SM40-100-R0 | SD-06-79 | DS-A00T | DS-T156B | DS-T15B1 | DT-35-02 |
| 25J3P-20035D1R01 | SM40-100-R0 | SD-06-B2 | DS-A00T | DS-T156B | DS-T15B1 | DT-35-02 |
| 25J3P-20035D1R02 | SM40-100-R0 | SD-06-B2 | DS-A00T | DS-T156B | DS-T15B1 | DT-35-02 |
| 25J3P-25040D3R01 | SM40-100-R0 | SD-08-D3 | DS-A00T | DS-T156B | DS-T15B1 | DT-35-02 |
| 25J3P-30037D4R01 | SM40-100-R0 | SD-10-54 | DS-A00T | DS-T156B | DS-T15B1 | DT-35-02 |
| 25J3P-30050D4R10 | SM40-100-R0 | SD-10-04 | DS-A00T | DS-T156B | DS-T15B1 | DT-35-02 |
| 25J3P-40050D5R01 | SM40-100-R0 | SD-12-79 | DS-A00T | DS-T156B | DS-T15B1 | DT-35-02 |
