  • Unique geometry
  • Best chatter free tools for high removal rates when machining titanium

(up to 2xD full slotting)

  • 4 flute endmills with differential helix and variable pitch
  • Large variety of corner radii

SERIES 47DRX

4-FLUTE ENDMILLS FOR MACHINING TITANIUM WITH DIFFERENT HELIX, CHAMFERED CUTTING EDGES & VARIABLE PITCH FOR CHATTER DAMPENING.

37° 35° D1 L1

R D2

L3

HelixD1ZRL3 OverallL1 CutD2 Shank
Cutter Number(deg)DiameterFlutesRadiusLengthLengthSize/Style
47D00408T7RX570 IN200535-374mm40.20057mm8mm6mm Cylind.
47D00510T7RX570 IN200535-375mm40.20057mm10mm6mm Cylind.
47D00612T7RX570 IN200535-376mm40.20057mm12mm6mm Cylind.
47D00612WERX570 IN200535-376mm40.20057mm12mm6mm Weldon
47D00816WSRX630 IN200535-378mm40.40063mm16mm8mm Cylind.
47D00816ZSRX630 IN200535-378mm40.40063mm16mm8mm Weldon
47D01020T1RX720 IN200535-3710mm40.50072mm20mm10mm Cylind.
47D01020W1RX720 IN200535-3710mm40.50072mm20mm10mm Weldon
47D01224T2RX830 IN200535-3712mm40.60073mm24mm12mm Cylind.
47D01224W2RX830 IN200535-3712mm40.60073mm24mm12mm Weldon
47D01632T3RX920 IN200535-3716mm40.80092mm32mm16mm Cylind.
47D01632W3RX920 IN200535-3716mm40.80092mm32mm16mm Weldon
47D02040T4RX104 IN200535-3720mm41.000104mm40mm20mm Cylind.
47D02040W4RX104 IN200535-3720mm41.000104mm40mm20mm Weldon
