РАДИАЛЬНАЯ РЕГУЛИРОВКА

Диаметр сверла	Пластина	Макс. радиальное отклонение (X)	Макс. диаметр
0.563" (14.3mm)	SOMT 050204 SK	0.015	0.593
0.594" (15.0mm)		0.013	0.620
0.626" (15.9mm)		0.011	0.648
0.657" (16.7mm)	SOMT 060204 SK	0.018	0.693
0.688" (17.5mm)		0.013	0.714
0.719" (18.3mm)		0.011	0.741
0.750" (19.1mm)	SOMT 070306 SK	0.010	0.770
0.781" (19.8mm)		0.020	0.821
0.813" (20.6mm)		0.015	0.843
0.843" (21.4mm)	SOMT 08T306 SK	0.011	0.865
0.875" (22.2mm)		0.008	0.891
0.906" (23.0mm)		0.025	0.956
0.938" (23.8mm)	SOMT 09T308 SK	0.022	0.982
0.969" (24.6mm)		0.018	1.005
0.984" (25.0mm)		0.015	1.014
1.000" (25.4mm)		0.015	1.030
1.031" (26.2mm)	SOMT 11T308 SK	0.011	1.053
1.063" (27.0mm)		0.028	1.119
1.094" (27.8mm)		0.024	1.142
1.125" (28.6mm)		0.015	1.155
1.156" (29.4mm)		0.015	1.186
1.187" (30.2mm)	SOMT 11T308 DP	0.011	1.209
1.219" (31.0mm)		0.008	1.235
1.250" (31.8mm)		0.035	1.320
1.281" (32.5mm)		0.031	1.343
1.312" (33.3mm)	SOMT 11T308 DP	0.031	1.374
1.343" (34.1mm)		0.028	1.399
1.375" (34.9mm)		0.024	1.423
1.406" (35.7mm)	SOMT 130408 DP	0.015	1.436
1.437" (36.5mm)	SOMT 130408 DP	0.047	1.531
1.468" (37.3mm)		0.047	1.562
1.500" (38.1mm)		0.039	1.578
1.531" (38.9mm)		0.035	1.601
1.562" (39.7mm)		0.028	1.618
1.594" (40.5mm)		0.024	1.642
1.625" (41.3mm)		0.024	1.673
1.687" (42.8mm)		0.012	1.711
1.719" (43.7mm)		SOMT 150510 DP	0.047	1.813
1.750" (44.5mm)	0.043		1.836
1.781" (45.2mm)	0.043		1.867
1.813" (46.0mm)	0.039		1.891
1.875" (47.6mm)	0.028		1.931
1.937" (49.2mm)	0.024		1.985
1.969" (50.0mm)	0.020		2.009
2.000" (50.8mm)	0.015		2.030
