GBP 57 ​Hydraulic pipe bender Sturdy hydraulic pipe bender with closed-loop hydraulic system and return spring for better piston control. Cast iron slide blocks and bending formers, high-performance piston with 450 bar working pressure. High- quality piston seals prevent leakage and extend the working life. Slide blocks feature bending angle indicator. Safe bending of pipes with closed-loop system. Special lever design prevents overloading. Supplied in a lockable wooden case. Application: For bending galvanised and black steel pipes and also gas pipes (3/8 inch − 2 inch). Bending angles up to 90°, pipes up to maximum 5.5 mm wall thickness (2 inch pipe). User- friendly operation thanks to a long piston stroke for each pump stroke. General-purpose use in machine tool and plant installation, working on pipework systems, fitting work etc. 82 1150 Type 3/8-1.1/4 3/8-2 82 1150 Hydraulic pipe bender eShop eShop 83R mm 45; 50; 65; 100; 130 45; 50;150;65; 100; 130; Bending radius (centre of pipe) 200 Content: Size 3/8; 1/2; 3/4; 1; Size 3/8; 1/2; 3/4; 1; 1 each bending segment No. 821155 1.1/4 1.1/4; 1.1/2; 2 Slide block No. 821156 2 pcs. hydraulic pipe bender 1 pc. Support wheels 3 pcs. For soft copper pipes to EN 1057 up to 22 mm (including those with thermal insulation), and for precision mild steel pipes to EN 10305-3 (DIN 2394) up to 18×1.5 mm. With hydraulic drive for a low applied force. Bending angles up to 90°. Supplied with: Hydraulic bending tool, 7 forming segments, 3 reaction pieces, plastic box. 82 1250 63M Manual pipe bender set hydraulic eShop Weight kg 6.2 82 1250 for pipe outer ⌀ mm 10; 12; 14; 15; 18; 20; 22 ​ Copper pipe bending pliers For bending angles up to 180° with smallest possible radius and no deformation of the pipe. Forming segment with graduations. Lightweight design for non-fatiguing work. Non-slip handle. Application: For bending soft copper pipes. Reverse curves can be bent in all directions, without transitions or shoulders, because the pliers can also be set in the middle of the pipe. 82 1310 for pipe outer ⌀ mm 6 8 10 12 82 1310 82A Copper pipe bending pliers eShop eShop eShop eShop Bending radius (centre of pipe) mm 18 24 30 36 Pipe bender “Sinus” Universal, robust hand-held pipe bender for cold draw bending of pipes. Forming 82 segments and slide blocks are of fibreglass-reinforced polyamide, i.e. very resistant but at the same time lightweight. The bending formers can be exchanged to deal with various pipe ⌀. The pipe bender can be fixed in a vice or held in the hand. Application: For bending both soft and hard copper pipes, thermally insulated copper pipes, steel pipes as well as aluminium and stainless steel pipes in sizes 10 − 22 mm outside diameter (12 -18 mm for stainless steel pipes). Bending angles up to 180°. (Max. wall thickness of pipes 1.5 mm, soft copper up to 3 mm, stainless steel up to 1.5 mm.) Supplied with: Bending drive of hardened steel, plug-in bolts, 4 bending formers, 4 slide 82 2011 blocks, and special bending spray, all in a sheet metal carrying case. for pipe outer ⌀ mm 12-22 82 2011 84C Pipe bender “Sinus” with bending segments, in a carrying case eShop Content: 1 pc. Pipe bender 1 each bending segment for pipe external ⌀ 12; 15; 18; 22 mm 1 each slide block for pipe external ⌀ 12; 15; 18; 22 mm 879
