GBP 57 ​ Pin punch with handle Sturdy octagonal shank with cylindrical shaft. Uniformly through hardened over the entire length. Head specially annealed to prevent splintering. Actual ⌀ 0.05 - 0.5 mm less than nominal ⌀, prevents the pin punch jamming in the hole. Material: Special quality extra chrome vanadium steel (i.e. the highest possible peak hardness - approx. 59 HRC - combined with special toughness), chrome-plated. Hand grip with a non-allergenic elastomer coating. Tip ⌀ mm 2 3 4 5 6 8 74 6940 Pin punch with handle eShop eShop eShop eShop eShop eShop 73B Pin length mm 47 52 67 72 82 88 overall length mm 140 145 175 180 205 210 Number of pin punches 6 Pin punch set with handle in an ABS plastic 74 6950 eShop 73B box Content: Size 2; 3; 4; 5; 6; 8 1 each pin punch No. 746940 ​ Pin punch with handle Round steel with cylindrical shaft, through hardened. “Impact damping” safety handle for increased comfort and precision. Head specially annealed to prevent splintering. 74 7100 L1 L2 S Tip ⌀ mm 3 4 5 6 8 10 12 14 16 74 7100 Pin punch with handle eShop eShop eShop eShop eShop eShop eShop eShop eShop 73R overall length L1 mm 150 190 200 210 216 230 280 290 310 Mandrel length L2 mm 45 60 70 80 86 100 130 140 160 Shank ⌀ S mm 8 10 10 12 12 14 16 18 18 74 Cut drawing Number of pin punches 4 5 74 7110 Pin punch set with handle eShop eShop 73R Content: Size 3; 4; 5; 6; 8 in a plastic box Size 10; 12; 14; 16 74  7110_5 1 each pin punch No. 747100 ​ Pin punches with guide sleeve Material: Chrome vanadium steel. Slim design with knurled guide sleeve and hardened arbor. Sizes 0.9 − 3.9 with loose guide sleeve − sizes 4.9 + 5.9 with fixed shank. 74 8000 Tip ⌀ mm 0,9 1,4 1,8 2,4 2,8 3,4 3,9 4,9 5,9 74 8000 Pin punch with guide sleeve eShop eShop eShop eShop eShop eShop eShop eShop eShop 72C Pin length mm 15 17 20 21 24 27 30 34 35 overall length mm 70 81 84 92 95 97 100 102 103 Number of pin punches 9 Pin punch set with guide sleeve 74 8201 eShop 72C in plastic wallet Pin punch set with guide sleeve 74 8205 eShop 72C in a metal case Content: Size 0.9; 1.4; 1.8; 2.4; 2.8; 3.4; 3.9; 4.9; 5.9 1 each pin punch with guide sleeve No. 748000 74 8201 74 8205 816
