GBP 57 A Grinding points mixed aluminium oxide (AW-AN) Grinding point in special quality mixed aluminium oxide, 30 grit (coarse), and ceramic bonding. Shank ⌀ 6 mm, shank length 40 mm. Application: For coarse grinding of cast iron and stainless steel. Recommended cutting speed 40 − 50 m/s. Type ZY1632 ZY2025 ZY2040 ZY3232 SP2032 Grinding point 55 1700 AW-AN eShop eShop eShop eShop eShop 10 51E coarse Head ⌀ mm 16 20 20 32 20 ​ Head length mm 32 25 40 32 32 ​ Shank ⌀ mm 6 ​ _ZY _SP SiC Silicon carbide (SiC) grinding points Ceramic bonded SiC grinding points, 80 grit (fine), with high self-sharpening effect and open-pore structure for improved reduction of clogging. Shank ⌀ 6 mm, shank length 40 mm. Application: For grinding aluminium alloys and soft materials (non-ferrous metals). Recommended circumferential speed 25 −40 m/s. Type Grinding point ZY1013 ZY1020 ZY2025 ZY4020 KE1632 55 55 1780 SiC eShop eShop eShop eShop eShop 10 56L fine Head ⌀ mm 10 10 20 40 16 ​ Head length mm 13 20 25 20 32 ​ Shank ⌀ mm 6 ​ _ZY _KE CER Grinding points mixed grit (AD-CER) Grinding point with mixed grit (AW-CER) in hardness J. Soft bonded combination of white aluminium oxide and ceramic micro-crystalline sintered aluminium oxide with high self-sharpening characteristics for consistently high metal removal rates coupled with cool grinding behaviour (Pferd designation AWCO). Assortment of grinding points in the most popular shapes and sizes. Application: For surface grinding of superalloys that are difficult to grind such as titanium materials, nickel and cobalt-based alloys, and also hardened steel. Recommended cutting speed 30 − 50 m/s. Supplied with: 1 each grinding point ZY0205 / ZY0306 / ZY0408 / ZY0510 / ZY0613 / ZY0816 / ZY1303 / ZY2006 / KU03 / KU06 / KU08 / SP0306 / SP0408 / SP0613 / SP0816. Grinding point set ​ Shank ⌀ Shank length Number of grinding points 15 mm mm Grinding point set 55 0305 AW-CER eShop 3 30 55E fine SiC Marbling points, PU-bonded Silicon carbide (SiC) in 46 grit resiliently bonded in plastic (PU) and mounted on a backing pad, with 6 mm steel shank. Application: For marbling and decorative effects on steel, stainless steel, non-ferrous metals. ​ 55 2000 ● ● ● ● ● ● ○ ● ● ○ ● ● ● Head ⌀ mm 30 40 50 55 2000 Marbling point eShop eShop eShop 10 51E Head ⌀ mm 30 40 50 ​ Head length mm 30 ​ Shank ⌀ mm 6 ​ Shaft length mm 40 ​ maximum speed min-1 10000 7500 6000 ​ 55 2000 335
