GBP 57 ​ Accessories for styli With M2 thread, shank ⌀ 3.0 mm. Note: Stylus extensions and adaptors in other sizes available on request. 49 4214 49 4215 Length mm 5 10 20 30 40 50 49 4214 (eShop) eShop eShop eShop eShop – 49F 49F Stylus extension 49 4215 – – – (eShop) (eShop) (eShop) Material (49 4214) stainless steel stainless steel stainless steel stainless steel stainless steel – Material (49 4215) – – – Ceramic Ceramic Ceramic Weight (49 4214) g 0.2 0.4 0.9 1.4 1.8 – Weight (49 4215) g – – – 0.97 1.22 1.51 49 Size M3/M2 – With M2 internal thread and M3 external thread. Size M4/M2 – With M2 internal thread and M4 external thread. Type M3/M2 M4/M2 49 4218 Adaptor eShop eShop 49F Weight g 0.6 1.5 49 4218 With M2 connection thread for accepting up to five different probes with M2 threads. Type M2/5 49 4219 5-way stylus centre M2 eShop 49F Weight g 0.8 49 4219 ​ Cleaning kit Application: For cleaning the contact faces of contact points, probe modules, and extensions. Simply pressing it on removes dirt and deposits gently. All contact faces should be cleaned regularly so as to ensure and maintain the reliability of the probe system. 49 4240 Stylus cleaning kit eShop 49F ​Coordinate plug gauge Coordinate plug gauge for determination of the position and alignment of internal threads using a coordinate measuring instrument or tactile MM1 measuring microscope with the tactile TP20 measuring system. Application: The plug supports itself by means of a difference in pitch between two successive turns of the thread and thus centres itself on the flanks of the thread. The probe measures the alignment in space of the smooth functional faces. L1 L1 L1 _M8 L2 L2 L2 L3 A L3 L3 A SW SW SW ØD ØD 0,005 A 0,005 A 0,003 0,003 Thread M3 M4 M5 M6 M8 M10 M12 M14 M16 49 4250 Coordinate plug gauge (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) 48B Material Gauge steel ⌀ D mm 6 6 6 6 8 10 12 14 16 Width across flats AF mm 4 4 4 4 6 8 10 12 14 Dimension L1 mm 26 29 29 31 41 49 59 67 73 Dimension L2 mm 12 12 12 12 16 20 24 28 32 Dimension L3 mm 5 7 8 10 13 15 18 20 20 264
